Volkswagen New Beetle. Manual - part 1317

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test requirements

z

Battery Voltage OK.

Test sequence

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 31: Connecting VAG1598/22 Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Bridge sockets with jumper wires from VW 1594 kit.

z

Up to MY 1999: sockets 33 + 1

z

From 2000: sockets 18 + 4

z

Measure Voltage between following sockets:

z

Up to MY 1999: sockets 2 + 1, 28 + 1, 27 + 2 and 28 + 27

z

From 2000: sockets 1 + 4, 2 + 4, 1 + 5, 2 + 5

z

Specification: approx. battery Voltage

If specification not obtained:

z

Check power supply relay -J31-, terminal 30.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

-J317- located on fuse relay panel above the central electric.

z

Check wiring for open circuit, short circuit and transfer resistance at terminals using Wiring diagram.

If wiring and relay OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

Engine speed (RPM) sensor -G28-, checking

Engine speed (RPM) sensor -G28- serves dual purpose of speed and reference mark sensor. An inoperative
sensor will stop engine.

Special tools

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Switch OFF ignition.

z

Disconnect -G28- harness connector. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW .

z

Measure resistance between connector terminals 1 + 2.

z

Specification: 1000 to 1500 ohm

Fig. 32: Identifying Engine RPM Sensor Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



If specification not obtained:

z

Replace Engine Speed sensor -G28-.

See ENGINE, DISASSEMBLING AND ASSEMBLING .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 33: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and 3-pin harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 34: Identifying Engine RPM Sensor Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 69

z

Terminal 2 + socket 67

z

Terminal 3 + socket 71

From MY 2000

z

Terminal 1 + socket 102

z

Terminal 2 + socket 110

z

Terminal 3 + socket 86

z

Wire resistance: 1.5ohm maximum

z

Check wiring for short circuit to one another at 3-pin harness connector using Wiring diagram.

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Manifold Absolute Pressure (MAP) Sensor -G71- and Barometric Pressure (BARO) Sensor -F96-, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
