Volkswagen New Beetle. Manual - part 1290





z

Ignition switched off.

Test sequence

z

Remove front noise insulation.

z

Disconnect 2-pin connector from motor for secondary air pump (arrow).

Fig. 16: Disconnecting 2-Pin Connector From Motor For Secondary Air Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect pressure hose at Secondary Air Injection (AIR) pump motor (arrow).

Fig. 17: Disconnecting Pressure Hose At Secondary Air Injection Pump Motor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect Secondary Air Injection (AIR) Pump Motor to the B+ and Ground (GND) terminals of the

NOTE:

To disengage, compress the buttons at the hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



battery using the respective adapter cables.

The Secondary Air Injection (AIR) Pump Motor must start up and air must escape at compressed-air
connection (arrow).

Fig. 18: Connecting Secondary Air Injection Pump Motor To B+ And Ground Terminals Of
Battery

Courtesy of VOLKSWAGEN OF AMERICA, INC.

If the motor does not start up, or no air or only very little air escapes:

z

Disconnect connection between Secondary Air Injection (AIR) Pump Motor and battery.

z

Replace Secondary Air Injection (AIR) Pump Motor -V101-:

z

Vehicles with engine code AEG, AVH, AZG. See item 8 .

z

Vehicles with engine code BDC. See item 6 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

If motor starts, and air escapes:

z

Disconnect connection between Secondary Air Injection (AIR) Pump Motor and battery.

z

Remove Secondary Air Injection (AIR) pump relay from relay carrier in protective housing for control
modules:

z

Vehicles with engine code AEG, AVH, AZG. See item 4 .

z

Vehicles with engine code BDC. See Secondary Air Injection (AIR) pump relay -J299-* (arrow) .

NOTE:

z

Remove battery Ground (GND) strap if tools are necessary for removal of



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Continuation for all vehicles

z

Check wire between terminal 2 of relay carrier and terminal 2 of 2-pin connector of Secondary Air
Injection (AIR) Pump Motor for open circuit according to wiring diagram. Wire resistance: max. 1.5 ohm

Fig. 19: Identifying Secondary Air Injection Pump Motor Wiring Harness Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Also check the wire for short circuit to B+ and Ground (GND). Specified value: INFINITY ohm

z

Check wire between 2-pin connector terminal 1 and Ground (GND) for open circuit according to wiring
diagram. Wire resistance: max. 1.5 ohm

If no malfunctions are found in wires:

z

Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL
MODULE (ECM)
 .

Combination valve, checking

Vehicles with engine code AEG up to 05.99:

Vehicles with engine code AEG as of 06.99, AVH, AZG, BDC. See Vehicles with engine code AEG as of
06.99, AVH, AZG, BDC
 .

Recommended special tools and equipment

z

VAG1390 Hand Vacuum Pump

Test requirements

relays or control modules from the relay carrier.

z

Obtain radio code for radios with anti-theft coding before disconnecting
battery.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

No leaks in vacuum lines or hose connections.

z

Vacuum hoses not clogged or kinked

z

Pressure hose for Secondary Air Injection (AIR) Pump Motor not clogged or kinked

Test sequence

z

Remove front noise insulation.

z

Disconnect vacuum hose -1- from combination valve at Secondary Air Injection (AIR) solenoid valve
(N112) -2-. See Fig. 20 .

Fig. 20: Testing Combination Valve At Secondary Air Injection Solenoid Valve (Engine Code AEG:
Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect hand vacuum pump (VAG1390) at vacuum hose -1- to combination valve.

z

Disconnect pressure hose at Secondary Air Injection (AIR) pump motor (arrow) and blow into it with
light pressure. Combination valve must close.

z

Operate vacuum pump. Combination valve must open.

If the combination valve does not open or it is constantly open:

z

Replace combination valve. See item 20 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING

NOTE:

Do not use pressurized air for the following test!

NOTE:

To disengage, compress the buttons at the hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle
