Volkswagen New Beetle. Manual - part 1289





z

Select the measuring value "Test-ID 03: Secondary Air Injection (AIR) system" and check whether the
specified values are being reached. See DIAGNOSTIC MODE 6: CHECK TEST RESULTS OF
COMPONENTS THAT ARE NOT CONTINUOUSLY MONITORED
 .

z

End diagnosis and switch ignition off.

If the specified values are not reached:

Checking Proper Seal

z

Check the connection pipes and hoses between Secondary Air Injection (AIR) pump motor and
combination valve for proper seal.

Secondary Air Injection (AIR) system components, removing and installing:

z

Vehicles with engine code AEG, AVH, AZG. See PARTS OF SECONDARY AIR INJECTION
(AIR) SYSTEM, REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE
AEG, AVH, AZG)
 .

z

Vehicles with engine code BDC. See PARTS OF SECONDARY AIR INJECTION (AIR)
SYSTEM, REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE BDC)
 .

z

Repeat function test.

z

Check hoses and hose connections for secure seating.

z

Repeat function test.

If malfunction is no longer present:

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 6: CHECK TEST
RESULTS OF COMPONENTS THAT ARE NOT CONTINUOUSLY MONITORED
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

Secondary Air Injection (AIR) Solenoid Valve (Vehicles with engine code AEG up to 05.99), checking

Solenoid valve is closed when no voltage is present.

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

Main fuses must be OK.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Fig. 11: Identifying Main Fuses (Secondary Air Injection Solenoid Valve: Engine Code AEG Up To
05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Ignition switched off.

Test sequence

z

Disconnect 2-pin connector from Secondary Air Injection (AIR) Solenoid Valve -N112- (arrow).

Fig. 12: Disconnecting 2-Pin Connector From Secondary Air Injection Solenoid Valve -N112-
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between terminals of solenoid valve.

Specified value: 25,0...35,0 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Fig. 13: Measuring Resistance Between Terminals Of Secondary Air Injection Solenoid Valve
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

If specified value is not obtained:

z

Replace Secondary Air Injection (AIR) Solenoid Valve -N112-. See item 2 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

If specified value is obtained:

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING
 .

z

Check wire between test box socket 33 + 2-pin connector terminal 2 for open circuit according to wiring
diagram. Wire resistance: max. 1.5 ohm

Fig. 14: Identifying Secondary Air Injection Solenoid Valve 2-Pin Harness Connector Terminals
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

Also check the wire for short circuit to B+ and Ground (GND).

Specified value: INFINITY ohm

z

Check wire between 2-pin connector terminal 1 and the Fuel Pump (FP) Relay -J17- for open circuit
according to wiring diagram. Wire resistance: max. 1.5 ohm

If no malfunctions are found in wires:

z

Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL
MODULE (ECM)
 .

Secondary Air Injection (AIR) pump motor, checking

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

Main fuses must be OK.

Fig. 15: Identifying Main Fuses (Secondary Air Injection Pump Motor)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fuel Pump (FP) Relay -J17- must be OK.

z

Secondary Air Injection (AIR) Pump Relay -J299- must be OK.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle
