Volkswagen New Beetle. Manual - part 1260





Fig. 9: Identifying Parts Of Secondary Air Injection System (Vehicles With Engine Code BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Secondary Air Injection (AIR) pump relay -J299-* (arrow)

In protective housing for relays in engine compartment (inserted in wiring beside master brake cylinder).

Fig. 10: Identifying Secondary Air Injection (Air) Pump Relay -J299-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Secondary Air Injection (AIR) system, checking for proper seal

Function test

NOTE:

z

Remove battery Ground (GND) strap if tools are necessary for removal of
relays or control modules from the relay carrier.

z

Obtain radio code for radios with anti-theft coding before disconnecting
battery.

z

Checking relay activation:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

Select the measuring value "Test-ID 03: Secondary Air Injection (AIR) system" and check whether the
specified values are being reached. See DIAGNOSTIC MODE 6: CHECK TEST RESULTS OF
COMPONENTS THAT ARE NOT CONTINUOUSLY MONITORED
 .

z

End diagnosis and switch ignition off.

If the specified values are not reached:

Checking Proper Seal

z

Check the connection pipes and hoses between Secondary Air Injection (AIR) pump motor and
combination valve for proper seal.

Secondary Air Injection (AIR) system components, removing and installing:

z

Vehicles with engine code AEG, AVH, AZG. See PARTS OF SECONDARY AIR INJECTION
(AIR) SYSTEM, REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE
AEG, AVH, AZG)
 .

z

Vehicles with engine code BDC. See PARTS OF SECONDARY AIR INJECTION (AIR)
SYSTEM, REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE BDC)
 .

z

Repeat function test.

z

Check hoses and hose connections for secure seating.

z

Repeat function test.

If malfunction is no longer present:

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 6: CHECK TEST
RESULTS OF COMPONENTS THAT ARE NOT CONTINUOUSLY MONITORED
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

Secondary Air Injection (AIR) Solenoid Valve (Vehicles with engine code AEG up to 05.99), checking

Solenoid valve is closed when no voltage is present.

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

Main fuses must be OK.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Fig. 11: Identifying Main Fuses (Secondary Air Injection Solenoid Valve: Engine Code AEG Up To
05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Ignition switched off.

Test sequence

z

Disconnect 2-pin connector from Secondary Air Injection (AIR) Solenoid Valve -N112- (arrow).

Fig. 12: Disconnecting 2-Pin Connector From Secondary Air Injection Solenoid Valve -N112-
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between terminals of solenoid valve.

Specified value: 25,0...35,0 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Fig. 13: Measuring Resistance Between Terminals Of Secondary Air Injection Solenoid Valve
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

If specified value is not obtained:

z

Replace Secondary Air Injection (AIR) Solenoid Valve -N112-. See item 2 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

If specified value is obtained:

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING
 .

z

Check wire between test box socket 33 + 2-pin connector terminal 2 for open circuit according to wiring
diagram. Wire resistance: max. 1.5 ohm

Fig. 14: Identifying Secondary Air Injection Solenoid Valve 2-Pin Harness Connector Terminals
(Engine Code AEG: Up To 05.99)

Courtesy of VOLKSWAGEN OF AMERICA, INC.
