z Also check the wire for short circuit to B+ and Ground (GND). Specified value: INFINITY ohm z Check wire between 2-pin connector terminal 1 and the Fuel Pump (FP) Relay -J17- for open circuit If no malfunctions are found in wires: z Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL Secondary Air Injection (AIR) pump motor, checking Recommended special tools and equipment z VAG1526 multimeter or VAG1715 multimeter z VAG1594 connector test kit z Wiring diagram Test requirements z Main fuses must be OK. Fig. 15: Identifying Main Fuses (Secondary Air Injection Pump Motor) z Fuel Pump (FP) Relay -J17- must be OK. z Secondary Air Injection (AIR) Pump Relay -J299- must be OK. z Battery voltage must be at least 11.5 volts. z All electrical consumers such as, for example, lights and rear window defroster must be switched off.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle
|
