Fig. 2: Identifying Exhaust Manifold, Front Exhaust Pipe With Three Way Catalytic Converter And
Attachments (Vehicles With Engine Code AVH, AZG, BDC)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Mufflers with mounts

1. From Three Way Catalytic Converter (TWC)

2. Double clamp

z

replace

z

Note installed position. See Installation position of double clamp .

3. 25 Nm

4. Suspended mount

z

Note installed position. See Installation position of muffler suspension .

5. Front muffler

z

At factory, front and rear mufflers are installed as a single component. Replacement front and rear
mufflers are supplied separately, with replacement double clamp for connecting joint.

z

Install front muffler parallel. See Aligning front muffler parallel .

6. Separating point

z

Separation point at exhaust pipe. See Separation point at exhaust pipe .

7. Suspended mount

8. Bracket

9. Rear muffler

z

At factory, front and rear mufflers are installed as a single component. Replacement front and rear
mufflers are supplied separately, with replacement double clamp for connecting joint.

10. Suspended mount

z

With retainer ring

NOTE:

The following list refers to Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



11. 20 Nm

12. Tunnel bridge

13. 40 Nm

14. Washer

Fig. 3: Identifying Mufflers With Mounts Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installation position of double clamp

Fig. 4: Identifying Installation Position Of Double Clamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work procedure

z

Position new double clamp as shown with approx. 5 mm distance to marking -A- and tighten it.
Tightening torque 40 Nm

z

Marking A (arrow 1) for vehicles with automatic transmission



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

Marking S (arrow 2) for vehicles with manual transmission

Installation position of muffler suspension

z

Angled side at foot of suspension (arrow) faces front of vehicle.

Fig. 5: Identifying Installation Position Of Muffler Suspension
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Separation point at exhaust pipe

Fig. 6: Identifying Separation Point At Exhaust Pipe
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Recommended special tools and equipment

z

Body saw, e.g. VAG1523

Work procedure

z

Separate exhaust pipe at right angle to separation point (arrow 2).

z

Position replacement double clamp -4- in installation position at the edge markings (arrows 1 and 3) as
shown when installing. Tightening torque 40 Nm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Aligning front muffler parallel

z

Mounting bolt at exhaust pipe must be parallel to tunnel bridge (dimension -x- same at left and right).

Fig. 7: Aligning Front Muffler Parallel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Catalytic converter, checking

Function test

z

Select the measuring value "Test-ID 01: Catalytic converter" and check whether the specified values are
being reached. See DIAGNOSTIC MODE 6: CHECK TEST RESULTS OF COMPONENTS THAT
ARE NOT CONTINUOUSLY MONITORED
 .

z

End diagnosis and switch ignition off.

If the specified values are exceeded:

z

Replace the front exhaust pipe with catalytic converter:

z

Vehicles with engine code AEG. See item 13 .

z

Vehicles with engine code AVH, AZG, BDC. See item 10 .

Continuation for all vehicles

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .
