INTERROGATION AND ERASING

z

Fuse for Secondary Air Injection (AIR) pump relay -J299- located in the main fuse box on the battery is
OK.

Fig. 22: Identifying Fuses Of Secondary Air Injection (AIR) Pump Relay Located In Main Fuse
Box

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secondary air injection pump vacuum lines and hose connections free of leaks.

z

Secondary air injection pump vacuum lines not blocked/kinked.

Work sequence

z

Remove engine cover.

z

Remove pressure hose (arrow) from secondary air injection pump motor.

Fig. 23: Removing Pressure Hose From Secondary Air Injection Pump Motor
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



z

Activate secondary air injection pump relay via final control diagnosis. See COMPONENTS AND
FUNCTIONS, ADAPTING
 .

z

Secondary air injection pump motor must run and air must exit outlet connection

If the motor runs, but no air exits:

z

Replace secondary air injection pump motor.

If the secondary air injection pump motor does not run at intervals:

z

Activate secondary air injection pump relay via final control diagnosis. See COMPONENTS AND
FUNCTIONS, ADAPTING
 .

z

Check activation of secondary air injection pump motor. See COMPONENTS AND FUNCTIONS,
ADAPTING
 .

SECONDARY AIR INJECTION SOLENOID VALVE, CHECKING

Only engine code AEG up to Model Year 1999, 05.99

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

Adapter set V.A.G 1594

Fig. 24: Identifying Adapter Set V.A.G 1594
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1527 B Diode test lamp

z

Wiring diagram

NOTE:

To release, press buttons together on hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 25: Identifying V.A.G 1527 B Diode Test Lamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Coolant temperature 5...33° C

z

Secondary air injection pump motor OK

Work sequence

z

Pull upper vacuum hose (arrow) off secondary air injection solenoid valve -1-.

Fig. 26: Disconnecting Upper Vacuum Hose From Secondary Air Injection Solenoid Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and run at idling speed.

z

When secondary air injection pump motor runs, a vacuum must be detectable at secondary air
injection pump union.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



If a vacuum cannot be detected:

z

Switch off ignition.

z

Disconnect 2-pin connector from secondary air injection solenoid valve.

z

Connect diode test lamp V.A.G 1527 B to disconnected connector using adapter cables from V.A.G 1594
C.

Fig. 27: Connecting Diode Test Lamp V.A.G 1527 B To Disconnected Secondary Air Injection
Solenoid Valve Connector

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and run at idling speed.

z

LED must light up

LED lights up (voltage supply OK):

z

Replace secondary air injection solenoid valve.

LED does not light up:

z

Connect 2-pin connector.

z

Check activation of valve. See COMPONENTS AND FUNCTIONS, ADAPTING .

z

Check wiring connections plate according to wiring diagram.

See appropriate WIRING DIAGRAMS article.

z

Interrogate fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATION AND ERASING
 .

z

Read readiness code. See COMPONENTS AND FUNCTIONS, ADAPTING .

z

If fault memory has been erased or engine control module separated from permanent positive power
supply, generate readiness code again. See COMPONENTS AND FUNCTIONS, ADAPTING
