Volkswagen New Beetle. Manual - part 1226





Fig. 17: Measuring Resistance Between Valve Contacts
Courtesy of VOLKSWAGEN OF AMERICA, INC.


If the specification is not obtained:

z

Replace Wastegate Bypass Regulator Valve -N75-.

z

Check DTC memory.

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

Read readiness code.

See Readiness Code, Displaying .

If the DTC memory has been erased or the engine control module separated from the permanent positive, the
readiness code must be generated again.

See Readiness Code, Displaying .

If the specification is obtained:

z

Check specified values in measuring value blocks for charge pressure regulation:

Display groups 111 to 119

z

Read Measuring Value Block, Display groups 110 to 119 -charge pressure control

See Measuring Value Block, Evaluating Display Groups 110...119 (Charge Pressure Control)

Charge Air Pressure Sensor -G31-, checking

Special tools and equipment

z

VAG 1526 A Hand multimeter

z

VAG1594A Adapter set

z

VAG 1598/31 Test box

z

Wiring diagram



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 18: Identifying Special Tools And Equipment



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions

z

On Board Diagnostic (OBD) has detected a malfunction with the Charge Air Pressure Sensor. Check and
erase DTC memory, if necessary:

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

Switch ignition off.

Checking voltage supply and wiring to control module

z

Disconnect 4-pin connector 2 from Charge Air Pressure Sensor -G31-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 19: Disconnecting 4-Pin Connector 2 From Charge Air Pressure Sensor -G31-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect multimeter to measure voltage using aux. cables from VAG1594 to contacts 1 (Ground) and 3
(positive) of connector for Charge Air Pressure Sensor.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
