z

Pistons must NOT be positioned at TDC.

Fig. 114: Identifying Oil Seals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PTFE sealing rings

z

Position oil seal with guide sleeve T10071 and press in onto limit stop with press sleeve T10071/1 and
bolt T10071/2.

Coil spring seals

z

Position oil seal with guide sleeve 10-203 and press in onto limit stop with press sleeve and bolt from 10-
203.

NOTE:

A PTFE seal (Teflon) -2 is gradually being introduced instead of the inner
coil spring seal -1-. This has a wider sealing lip. PTFE oil seals are
installed free of oil and grease. A radial shaft seal of older design (with coil
spring) may be replaced with a PTFE oil seal, but not vice versa. When a
PTFE oil seal is installed, then only such an oil seal may be installed as a
replacement part!

NOTE:

Do not additionally oil or grease the oil seal sealing lip.

NOTE:

Oil or grease lightly the oil seal sealing lip.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 115: Installing Cam Shaft Oil Seal With Guide Sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all seals

z

Insert woodruff key in camshaft.

z

Install camshaft pulley. To tighten securing bolt counter support camshaft pulley with 3415.

Tightening torque: 100 N.m

The rest of the assembly is basically in reverse order to the disassembly sequence.

Fig. 116: Installing Camshaft Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing toothed belt and adjusting timing. See TOOTHED BELTS, REMOVING, INSTALLING

NOTE:

When the camshaft is turned, the crankshaft must not be at TDC. Danger
of damage to valves or piston crowns.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



AND TENSIONING .

Camshaft, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

3415 Counter support

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

AMV174 004 01 Sealant

Fig. 117: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove engine cover.

z

Remove intake manifold upper part. See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING
 .

z

Remove toothed belt guard, upper part.

z

Set camshaft pulley to TDC No. 1 cylinder by turning crankshaft.

NOTE:

Seal the intake ports in the intake manifold lower section with clean cloths.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 118: Aligning Mark On Camshaft Sprocket With Arrow On Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Mark on camshaft sprocket must align with arrow on toothed belt guard.

z

Release tensioning roller and take toothed belt off camshaft pulley.

z

Turn crankshaft back slightly.

z

Remove camshaft pulley. To loosen camshaft pulley securing bolt, hold pulley with counter support 3415

Fig. 119: Removing Camshaft Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove woodruff key from camshaft.

z

Remove cylinder head cover.

z

First remove bearing caps 5, 1 and 3. Loosen bearing caps 2 and 4 alternately and diagonally.

Installing

Requirements



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
