Fig. 102: Identifying Cylinder Head Reworking Dimension (Cylinder Head Height) Cylinder head reworking dimension: -a- = min. 132.6 mm Checking Camshaft Axial Clearance Fig. 103: Checking Camshaft Axial Clearance Special tools, testers, measuring instruments and auxiliary items required z Universal dial gauge bracket VW 387 z Dial gauge Check with hydraulic lifters removed and with first and last bearing caps installed. NOTE: When the sealing surface has been reworked, the valves must be set deeper by
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
|
