z Engine oil temperature must be at least 30°C. z Voltage supply OK. z All electrical consumers, e.g. lights and rear window defogger must be switched off. z If the vehicle is equipped with air conditioning, this must be switched off. z On models with an automatic transmission selector lever in position "P" or "N" Work sequence z Remove engine cover. z Disconnect 6-pin connector from ignition coil with final output stage (arrow). Engine code AEG Fig. 98: Locating Engine Code AEG Engine codes AVH, AZG, BDC, BEV, BGD Fig. 99: Locating Engine Codes AVH, AZG, BDC, BEV, BGD z Pull fuse No. 32 out of fuse holder. Fuse box located under access cover at far left end of dash.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
|
