Volkswagen New Beetle. Manual - part 1171





Engine codes AEG, AVH, AZG

z

Pull fuel supply line -3-, fuel return line -2- and vacuum line -1- off at connecting point.

Fig. 86: Removing Fuel Supply Line, Fuel Return Line And Vacuum Line (Engine codes AEG,
AVH, AZG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect hose from EVAP canister purge regulator valve -N80-.

z

Disconnect fuel supply line -1- and fuel return line -2- from fuel rail and collect fuel that leaks out with a
clean cloth.

Fig. 87: Disconnecting Fuel Supply Line And Fuel Return Line From Fuel Rail (Engine Codes
AEG, AVH, AZG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BDC

z

Disconnect fuel supply line -1- and fuel return line -2- at connection point on fuel rail.

place a cloth around the connection. Then release pressure by
carefully loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 88: Disconnecting Fuel Supply Line And Fuel Return Line (Engine Code BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect hose from EVAP canister purge regulator valve -N80-.

Engine codes BEV, BGD

z

Pull fuel supply line -1- off union by pressing locking ring -2- into union -3- and collect fuel that leaks
out with a clean cloth.

Fig. 89: Disconnecting Fuel Supply Line (Engine Codes BEV, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all models

z

Seal lines to avoid contamination of fuel system.

z

Remove air cleaner assembly complete with air intake tube and secondary air injection tube. See AIR
CLEANER, DISASSEMBLING AND ASSEMBLING


z

Remove intake manifold upper part: See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING




2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Release all coolant, vacuum and intake hoses from intake manifold/cylinder head as required.

z

Pull off/disconnect all electrical wiring as necessary on cylinder head and place to side.

z

Disconnect coolant hose at connecting unions.

z

Remove intake and pressure lines for secondary air injection pump.

z

Remove pressure line bracket.

z

Unbolt and remove secondary air injection pump motor and bracket.

z

Disconnect following connectors:

z

-1- for Secondary Air Injection (AIR) pump motor -V101-, -2-

Fig. 90: Disconnecting Secondary Air Injection (AIR) Pump Motor Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

For Camshaft Position (CMP) sensor -G40-

z

For Knock Sensor (KS) 1 -G61-

z

For injectors -N30-, -N31-, -N32-, -N33- (release from cable guide).

z

Engine Coolant Temperature (ECT) sensor -G62- (arrow).

z

Remove harness for Knock Sensor 1 -G61- from clip on Generator bracket.

NOTE:

Seal the intake ports in the intake manifold lower section with clean cloths.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 91: Disconnecting Engine Coolant Temperature (ECT) Sensor Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove clips securing fuel injector harness to fuel rail and place harness to side.

z

Unclip wiring harness from left side of cylinder head.

z

Remove ignition cables from spark plugs (use T10112).

z

Unclip coolant recovery hose from bracket -1- on top of toothed belt tensioner.

z

Remove bolt -2- securing oil dipstick tube to lower intake manifold.

Fig. 92: Removing Coolant Recovery Hose Clip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cover from oxygen sensor connectors on vehicle underside. See IDENTIFYING PIN
CONNECTOR OF HEATED OXYGEN SENSOR under ENGINE CODE BEV

z

Disconnect Heated Oxygen Sensor (HO2S) -G39- connector and unclip harness from exhaust heat shield.

z

Remove front exhaust pipe with catalytic converter.

z

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
