Pistons must not be positioned at TDC.

Work sequence

z

Oil running surfaces on camshaft.

z

Install camshaft.

z

Tighten bearing caps 2 and 4 alternately and diagonally to 20 N.m.

z

Coat contact surfaces of bearing cap 1 lightly with sealing compound AMV 174 004 01.

z

Install bearing caps 3, 1 and 5 and also tighten to 20 N.m.

z

Insert woodruff key in camshaft.

z

Install camshaft pulley. To tighten securing bolt counter support camshaft pulley with 3415.

Tightening torque: 100 N.m

NOTE:

z

When installing the camshaft, the cam lobes for cylinder 1 must face
upward.

z

When installing the bearing cap note offset. Before installing camshaft fit
bearing caps and determine installed position.

Fig. 120: Identifying Correct Installation Of Camshaft Bearing Cap
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 121: Installing Camshaft Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The rest of the assembly is basically in reverse order to the disassembly sequence.

Installing toothed belt and adjusting timing. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING
 .

Hydraulic lifters, checking

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

Feeler gauge

z

Wooden or plastic wedge

Work sequence

z

Start engine and run until coolant fan has switched on once.

z

Increase engine speed to about 2500 RPM for approx. 2 minutes.

NOTE:

When the camshaft is turned, the crankshaft must not be at TDC. Danger
of damage to valves or piston crowns.

NOTE:

When new lifters have been installed the engine must not be started for
about 30 minutes. The hydraulic compensation elements must settle
(otherwise valves will strike pistons).

NOTE:

z

Replace faulty hydraulic lifters complete only (can not be adjusted or
serviced).

z

Irregular valve noises when starting engine are normal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



If the hydraulic lifters are still noisy, locate faulty lifters as follows:

z

Remove intake manifold upper part. See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING
 .

z

Remove cylinder head cover.

z

Rotate crankshaft clockwise, until cam of lifter to be checked is pointing upward.

z

Determine clearance between cam lobe and hydraulic lifter.

z

If clearance is greater than 0.2 mm, replace hydraulic lifter. If clearance is less than 0.1 mm or no
clearance exists, then proceed with check as follows:

z

Push hydraulic lifter down lightly with a wooden or plastic wedge. If when hydraulic lifter is pushed
down a 0.2 mm thick feeler gauge can be inserted between camshaft and hydraulic lifter, lifter is to be
replaced.

Fig. 122: Pushing Hydraulic Lifter
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Valve guides, checking

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

VW 387 Universal dial gauge bracket

z

Dial gauge

NOTE:

Seal the intake ports in the intake manifold lower section with clean cloths.

NOTE:

When new lifters have been installed the engine must not be started for
about 30 minutes. The hydraulic compensation elements must settle
(otherwise valves will strike pistons).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 123: Identifying Special Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Insert a new valve into guide. End of valve stem must be flush with guide. Due to slight difference in
stem diameters, ensure that only an intake valve is used in intake guide and an exhaust valve in exhaust
guide.

Fig. 124: Checking Valve Guide Wear (Valve Rock)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Determine rock.

Wear limit:

Intake valve guide = 1.0 mm

Exhaust valve guide = 1.3 mm
