z

Crankshaft dimensions. See CRANKSHAFT DIMENSIONS

10. Thrust washer

z

For cylinder block, bearing 3

z

Lettering faces mounting bracket

Fig. 56: Exploded View Of Crankshaft Assembly (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Upper crankshaft bearing identification (gradual introduction)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 57: Locating Upper Crankshaft Bearing Identification Marks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

In the factory the upper bearing caps are allocated with the correct thickness for the cylinder block. Colored
marks are used to identify the thickness of the bearing shells. See CRANKSHAFT BEARING COLOR
MARKINGS
 .

Which thickness of shell should be installed to which location is marked by a letter on the lower sealing surface
of the cylinder block -x-.

Arrow indicates direction of travel (forward).

Crankshaft bearing color markings

CRANKSHAFT BEARING COLOR MARKINGS SPECIFICATIONS

Letter on cylinder block

Color of bearing

S =

Black

R =

Red



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Crankshaft dimensions

Dimensions in mm.

CRANKSHAFT DIMENSIONS SPECIFICATIONS

PISTON AND CONNECTING ROD, DISASSEMBLING AND ASSEMBLING

Gradual introduction of "industrially fractured" connecting rods.

G =

Yellow

NOTE:

z

If the colored marks have not been stamped or are no longer legible, use
the average bearing shell (red).

z

The lower crankshaft bearing shells are always supplied as a spare part
with the color marking "yellow".

Grinding dimension

(1)

Crankshaft bearing journal diameter

Connecting rod journal diameter

Basic dimension

-0.017

54.00

-0.037

-0.022

47.80

-0.042

1st undersize

-0.017

53.75

-0.037

-0.022

47.55

-0.042

2nd undersize

-0.017

53.50

-0.037

-0.022

47.30

-0.042

3rd undersize

-0.017

53.25

-0.037

-0.022

47.05

-0.042

(1)

All dimensions are in mm.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 58: Identifying "Industrially Fractured" Connecting Rods
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Distinguishing features:

A. Older type connecting rods (smooth joint along contact surface)

B. Industrially fractured connecting rods (rough joint along contact surface)

z

Disassembling and assembling piston and older type connecting rod. See OLDER TYPE
CONNECTING RODS


z

Disassembling and assembling piston and industrially fractured connecting rod. See INDUSTRIALLY
FRACTURED CONNECTING RODS


Older type connecting rods



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
