Volkswagen New Beetle. Manual - part 1161







2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 51: Securing Counter Support Tool To Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Position of counter support tool:

A. To loosen

B. To tighten

Installing drive plate

z

Locate drive plate and packing plate with recesses -1-.

z

Install new bolts -3- and tighten to 30 N.m.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 52: Installing Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure dimension -a- at three different outer holes of drive plate (120° offset) and calculate average.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Specification: 19.5...21.1 mm

Fig. 53: Measuring Clearance Between Drive Plate And Engine Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If the specification is not attained:

z

Remove drive plate again and install shim -2-. Again tighten bolts -3- to 30 N.m.

NOTE:

Measure through hole in drive plate to milled surface of cylinder block. To
do this unhook intermediate plate (See Fig. 32 ).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
