1. Piston rings

z

Offset gaps by 120°

z

Use piston ring pliers to remove and install

z

"TOP" faces piston crown

z

Checking ring gap. See Fig. 61

z

2-part oil scraper ring

2. Piston

z

Checking. See Fig. 63

z

Mark installation position and cylinder number

z

Arrow on piston crown points to belt pulley end

z

Checking ring to groove clearance. See Fig. 62

z

Install using piston ring clamp

3. Connecting rod

z

Only replace as a set

z

Mark allocation to cylinder -B-

z

Installation position: Marking -A- faces belt pulley end

4. Connecting rod bearing cap

z

Mark allocation to cylinder -B-

z

Installation position: Marking -A- faces belt pulley end

5. 30 N.m + 1/4 turn (90°) further

z

Replace

z

Oil thread and contact surface

z

To measure radial clearance tighten to 30 N.m, but do not turn further

6. Bearing shell

z

Observe installing position

z

Do not interchange used bearing shells

z

Ensure retaining lugs fit tightly in recesses

z

Upper bearing shell with oil drilling for piston pin lubrication

z

Axial clearance, new: 0.05 ... 0.31 mm; Wear limit: 0.37 mm

z

Check radial clearance with Plastigage, new: 0.01 ... 0.06 mm; Wear limit: 0.12 mm

z

Do not rotate crankshaft when checking radial clearance

7. Cylinder block

z

Checking cylinder bore. See Fig. 65

z

Piston and cylinder dimensions. See PISTON AND CYLINDER DIMENSIONS

8. Connecting rod bolt

NOTE:

The following list refers to items in Fig. 59 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



9. Circlip

10. Piston pin

z

If difficult to remove, heat piston to 60° C

z

Remove and install with VW 222a

Fig. 59: Exploded View Of Piston And Connecting Rod Assembly (Older Type Connecting Rods)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Industrially fractured connecting rods

1. Piston rings

z

Offset gaps by 120°

NOTE:

The following list refers to items in Fig. 60 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Use piston ring pliers to remove and install

z

"TOP" faces piston crown

z

Checking ring gap. See Fig. 61

z

Checking ring to groove clearance. See Fig. 62

z

Oil scraper ring 2- or 3-part

2. Piston

z

Checking. See Fig. 63

z

Mark installation position and cylinder number

z

Arrow on piston crown points to pulley end

z

Install using piston ring clamp

3. Floating piston pin

z

If difficult to remove, heat piston to 60 °C

z

Remove and install with VW 222A

4. Snap ring

5. Connecting rod

z

With cracked bearing cap

z

Only replace as a set

z

Mark relationship to cylinder -B-

z

Installation position: Marking -A- faces belt pulley end

6. Bearing shell

z

Observe installation position. See Fig. 64 .

z

Insert bearing shells centrally

z

Do not interchange used bearing shells

z

Check if seated securely

z

Axial clearance, new: 0.10...0.35 mm; Wear limit: 0.4 mm

z

Check radial clearance with Plastigage, new: 0.01...0.05 mm; Wear limit: 0.09 mm

z

Do not rotate crankshaft when checking radial clearance

7. Cylinder block

z

Checking cylinder bore. See Fig. 65

z

Piston and cylinder dimensions. See PISTON AND CYLINDER DIMENSIONS

8. Connecting rod bearing cap

z

Observe installing position

z

Caps only fit in one position and only on appropriate connecting rod due to breaking procedure
(industrially fracturing) separating cap from connecting rod

9. 30 N.m + 1/4 turn (90°) further

z

Torx E 10

z

Replace



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Oil thread and contact surface

z

To measure radial clearance tighten to 30 N.m, but do not turn further

Fig. 60: Exploded View Of Piston And Connecting Rod Assembly (Industrially Fractured Connecting
Rods)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Piston Ring Gap
