For Engine Speed sensor

7. 10 N.m (7 ft lb) plus additional 1/4 turn (90°)

z

Always replace

8. Fitted pin

z

Checking projection from crankshaft. See Crankshaft dowel pin projection, checking

9. Crankshaft

z

Axial clearance new: 0.07 to 0.17 mm Wear limit: 0.37 mm

z

Check radial clearance with Plastigage New: 0.03 to 0.08 mm Wear limit: 0.17 mm

z

Do not rotate crankshaft when checking radial clearance

z

Crankshaft dimensions. See CRANKSHAFT DIMENSIONS (MM)

10. Thrust washer

11. For engine block, bearing 3

Fig. 56: Exploded View Of Crankshaft & Main Bearing Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Crankshaft dowel pin projection, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 57: Checking Crankshaft Dowel Pin Projection
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dowel pin projection -3- out of crankshaft a = 2.5 to 3.0 mm

Crankshaft dimensions (mm)

CRANKSHAFT DIMENSIONS CHART

Honing dimension

Main journal diameter

Con-rod journal diameter

Basic
dimension

-0.022

54.00

-0.042

-0.022

47.80

-0.042

1st undersize

-0.022

53.75

-0.042

-0.022

47.55

-0.042

2nd undersize

-0.022

53.50

-0.022

47.30



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



PISTONS AND CONNECTING RODS, DISASSEMBLING AND ASSEMBLING

1. Piston ring

z

Offset ring gaps 120°

z

Remove and install using piston ring pliers

z

"TOP" faces towards crown

z

Ring gap, checking: See Piston ring gap, checking

z

Ring to groove clearance. See Ring to groove clearance, checking

2. Piston

z

Mark installation position and cylinder number

z

Arrow on piston crown points to: pulley end

z

Install using piston ring tool

z

If any cracks on piston skirt, replace piston

z

Piston projection at TDC, checking. See PISTON PROJECTION AT TDC, CHECKING

3. Piston pin

z

If difficult to remove, heat piston to 60 °C

z

Remove and install using VW 222A

4. Circlip

5. Connecting rod

z

Only replace as a set

z

Mark cylinder number -A-

z

Installed position: Marking -B- faces pulley end

6. Fitted pin

z

Pin must seat securely in connecting rod, not in bearing cap

7. Bearing shell

z

Note installed position

z

Do not interchange used bearing shells

z

Make sure retaining lugs fit tightly in recesses

z

Axial clearance Wear limit: 0.37 mm

z

Check radial clearance with Plastigage: Wear limit: 0.08 mm Do not rotate crankshaft while
checking.

8. Cylinder block

-0.042

-0.042

3rd undersize

-0.022

53.25

-0.042

-0.022

47.05

-0.042

NOTE:

The following list refers to items in Fig. 58 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Checking cylinder bores. See Cylinder bores, checking

z

Piston and cylinder dimensions: See PISTON AND CYLINDER DIMENSIONS IN MM

9. Connecting rod bearing cap

z

Note installed position

10. Oil spray jet

z

For piston cooling

11. 25 N.m (18 ft lb)

z

Install without sealant

12. Connecting rod bolt

z

30 N.m (22 ft lb) plus additional 1/4 turn (90°)

z

Always replace

z

Oil the threads and contact surfaces

z

Use old bolts to measure radial clearance



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
