Volkswagen New Beetle. Manual - part 1114





z

Cable tie

Fig. 3: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect fuel supply and return lines at fuel filter.

CAUTION: Obtain the radio anti-theft code from the customer BEFORE disconnecting

the battery Ground strap.

NOTE:

z

After making sure that the ignition is switched OFF, disconnect the battery
Ground strap.

z

All cable ties which were opened or cut open to remove the
engine/transmission assembly, must be replaced in the original position
when installing the engine.

z

Remove the engine/transmission assembly downward.

z

Remove the engine cover.

z

Remove power steering reservoir from battery support, thereby not having
to loosen the fluid hoses.

z

Attach coolant reservoir to upper radiator support.

z

Remove the battery and battery hold-down.

z

Remove Air Cleaner.

z

Remove connecting pipe between the Charge Air cooler and intake
manifold complete with EGR Vacuum Regulator solenoid valve -N18-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 4: Disconnecting Fuel Supply And Return Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal off lines so fuel system is not contaminated by dirt etc.

Vehicles with manual transmission

z

Disconnect selector mechanism from transmission.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, UP TO 5.99 DISASSEMBLING AND
ASSEMBLING
 or SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 6.99
DISASSEMBLING AND ASSEMBLING
 .

z

Remove hydraulic clutch slave cylinder:

See CLUTCH SLAVE CYLINDER

Vehicles with automatic transmission

z

Remove Transmission Range selector lever cable from transmission:

See SELECTOR LEVER CABLE

All vehicles

z

Remove sound dampening tray:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 5: Removing Sound Dampening Tray
Courtesy of VOLKSWAGEN OF AMERICA, INC.

See NOISE INSULATION, ASSEMBLY OVERVIEW

z

Drain engine coolant. See COOLING SYSTEM, DRAINING AND FILLING

z

Remove line between charge air cooler and turbocharger.

z

Pull radiator hoses off engine using VAG 1921 hose clip pliers.

z

Remove lower coolant hose from radiator.

z

Remove auxiliary filter, if available, on right side of vehicle.

z

Loosely unscrew pendulum support (arrows).

Fig. 6: Removing Pendulum Support Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull vacuum and breather hoses off engine.

z

Disconnect all wiring from the transmission, Generator and starter and move them to one side for
clearance.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Remove front exhaust pipe. See FRONT EXHAUST PIPE AND CATALYST WITH
ATTACHMENTS


z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove power steering pump with bracket and lay to one side.

z

Hoses remain connected:

See POWER STEERING PUMP, RESERVOIR, HYDRAULIC LINES .

z

Remove right hand inner Constant Velocity joint protective cover from engine if installed.

z

Remove right-hand drive shaft and disconnect left-hand drive shaft at transmission:

See FRONT AXLE SHAFT .

z

Unscrew mounting bolts for power steering pressure line.

Vehicles with A/C:

z

Observe additional information and removal instructions. See VEHICLES WITH A/C, ADDITIONAL
INFORMATION AND REMOVAL INSTRUCTIONS
 .

z

Remove starter.

See appropriate STARTERS article.

All vehicles:

z

Insert engine bracket 3396 into VAG 1383 A engine / transmission jack.

z

Remove coolant hose bracket and lower from cylinder block.

z

Thread hole is used to fasten T 10012 engine bracket

z

Thread on T 10012 engine bracket using M10x 25 5/ 8.8 nut and bolt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
