Volkswagen New Beetle. Manual - part 1115





Fig. 7: Threading On T 10012 Engine Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Attach to engine block with 25 Nm (18 ft lb)

z

Slightly lift engine/transmission assembly using VAG 1383 A jack.

z

Loosely unscrew engine mount (engine side) from top of engine bracket (arrows).

Fig. 8: Removing Engine Mount Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosely unscrew engine mount/transmission mount from transmission bracket (arrows) from top.

Fig. 9: Removing Engine Mount/Transmission Mount Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully lower engine/transmission assembly.

NOTE:

Use VAS 5085 tool to remove the mounting bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

While lowering, carefully guide the power steering fluid line past the transmission.

Engine assembly stand, attaching engine

Work sequence

z

Transfer Engine/transmission subassembly to workbench via VAG 1383 A engine/transmission jack.

Fig. 10: Identifying Transfer Engine/Transmission Subassembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lower the engine/transmission assembly such that the transmission is supported.

z

Remove lower engine/transmission connecting bolt.

z

Push transmission off engine, while pushing the torque converter out of the drive plate.

Vehicles with automatic transmission

z

Remove nut from torque converter.

z

Clamp off ATF cooler hoses and disconnect at transmission cooler.

z

Seal off transmission cooler using clean plugs.

z

Secure torque converter to prevent it from falling out.

All vehicles

NOTE:

Carefully guide the engine and transmission assembly during the lowering
process to prevent bodywork damage.

NOTE:

To work on the engine outside of the vehicle, attach engine to assembly stand
using the VW 313 holding fixture along with the VW 540 engine/transmission
support.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Attach 2024A engine sling using 2024 A/1 extension as follows and lift from VAG 1383
engine/transmission jack using workshop crane:

z

Pulley end: 4th hole in hook at position 1

z

Flywheel end: 4th hole in hook at position 8

Fig. 11: Attaching 2024A Engine Sling
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure engine to holding fixture VW 313 using VW 540 engine/transmission support and VW 540/1
supplementary kit.

Installation notes

Installation is reverse of removal, note the following during installation:

z

Check whether centering dowels for engine/transmission are installed in the cylinder block, install if
necessary.

z

Install intermediate plate onto sealing flange and slide onto dowel sleeves (arrows).

WARNING:

Secure ALL hooks and locating pins with lock pins!

NOTE:

z

Positions marked 1 to 4 on the bar must be located toward the pulley end
of the engine.

z

The holes in the hooks are counted up from the hook.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 12: Installing Intermediate Plate Onto Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with manual transmission

z

Check clutch release bearing for wear, replace if necessary.

z

Lightly grease clutch release bearing, release bearing guide sleeve and splines on input shaft using G 000
100.

z

Install hydraulic clutch slave cylinder:

See CLUTCH SLAVE CYLINDER

z

Install selector mechanism:

See SELECTOR MECHANISM .

z

If necessary adjust gear change cables:

See SELECTOR MECHANISM .

Vehicles with automatic transmission

z

Replace the lock washer on the selector cable anchorage.

z

Install selector cable on transmission, adjust if necessary:

See SELECTOR LEVER CABLE .

All vehicles

z

When installing the engine and transmission assembly, make sure sufficient clearance to drive shafts.

z

While raising, carefully guide the power steering fluid line past the transmission.

z

Engine and Transmission subassembly is aligned transversely so there is a distance between engine



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
