Volkswagen New Beetle. Manual - part 1112





Fig. 147: Identifying 3249 Socket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1331 Torque wrench (5 to 50 N.m)

z

Silicone sealant D 176 404 A2

z

Hand drill with plastic brush

z

Protective glasses

z

Flat scraper

Removing

z

Removing center and right insulation tray:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING .

z

Drain engine oil.

z

Detach turbocharger oil return pipe from oil pan.

z

Loosen oil pan bolts using extension socket wrench 3185. Unscrew with socket 3249.

z

Remove oil pan; it may be necessary to release oil pan by tapping lightly with a rubber head hammer.

z

Remove sealant residue on cylinder block with a flat scraper.

z

Remove sealant residue on oil pan with a rotating brush, e.g. a hand drill with a plastic brush (wear
protective glasses).

NOTE:

Observe disposal regulations!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 148: Removing Sealant Residue On Oil Pan With Rotating Brush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clean sealing surface; it must be free of oil and grease.

Installing

z

Cut off tube nozzle at forward marking (nozzle approx. 3 mm diameter).

Fig. 149: Cutting Off Tube Nozzle At Forward Marking
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply silicone sealing compound, as shown, to clean oil pan sealing surface.

Sealing compound bead must be:

z

2-3 mm thick

z

and run on inside of bolt holes -arrows-

NOTE:

z

Note the use by date of the sealant.

z

Oil pan must be installed within 5 minutes of applying silicone sealing
compound.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Apply silicone sealing bead as shown to clean sealing surface of oil pan (illustration shows position of
sealant bead on cylinder block).

Fig. 150: Applying Silicone Sealing Bead To Clean Sealing Surface Of Oil Pan
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install oil pan immediately and tighten bolts as follows:

1. Tighten all bolts oil pan/cylinder block very lightly and diagonally.

2. Lightly tighten three bolts oil pan/transmission.

3. Lightly tighten all bolts oil pan/cylinder block diagonally.

4. Tighten three bolts oil pan/transmission to 45 N.m.

5. Tighten all bolts oil pan/cylinder block diagonally to 15 N.m.

6. Tighten oil pan/oil return pipe to 10 N.m.

The rest of the assembly is basically a reverse of the disassembly sequence.

Oil pressure and oil pressure switch, checking

Special tools and equipment

NOTE:

The sealing compound bead must not be thicker, otherwise excess sealing
compound will enter the oil pan and may block the oil suction pipe
strainer.

NOTE:

z

When installing the oil pan on an engine which is out of vehicle,
ensure that the oil pan is flush with cylinder block on flywheel end.

z

The sealant must be allowed to dry for approx. 30 minutes after
installing the oil pan before the engine can be filled with engine oil.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 151: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1342 Oil pressure tester

z

VAG 1527 BLED test light

z

VAG 1594 A Adapter set

Function of the dynamic oil pressure warning indicator

z

When not under pressure, the oil pressure switch is open and will close when the operating pressure is
attained.

z

The oil pressure warning will be activated approx. 10 seconds after switching the ignition on.

z

Switch-in delay of oil pressure warning: approx. 3 seconds.

z

Switch-off delay of oil pressure warning: approx. 5 seconds.

See appropriate WIRING DIAGRAM article.

Checking warning lamp

After switching on the ignition without engine started, the oil pressure warning lamp in instrument cluster must
light for approx. 3 seconds and then go out. The test will be terminated if the engine is running.

Criteria for warning

Switching on the optical oil pressure warning (the oil pressure warning lamp flashes) and the buzzer sounding
three times for the acoustical warning will occur under one of the following conditions:

z

"Ignition on," engine stationary, oil pressure switch closed

NOTE:

Functional check and servicing the optical and acoustic oil pressure
warning:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
