Volkswagen New Beetle. Manual - part 1100





Fig. 91: Removing Fuse 32
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions

z

Engine oil temperature must be at least 30 °C.

Work sequence

z

Remove engine cover.

z

Pull connector(s) off ignition coils.

z

Remove ignition coils.

z

Remove spark plugs with spark plug removal tool 3122B.

z

Fully open throttle valve.

z

Check compressions with compression tester VAG 1381 / VAG 1763.

z

Operate starter until tester shows no further pressure increase.

Compression pressure:

z

New: 10-14 bar

z

Wear limit: 7.0 bar

z

Permissible difference between all cylinders: 3 bar

{

Thread in spark plugs with spark plug socket and extension 3122B and tighten to 30 N.m.

Vehicles with engine code: APH

z

Install ignition coils and tighten to 10 N.m.

NOTE:

Using the compression tester. See Operating instructions.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Vehicles with engine codes: AWP, AWV

z

Install ignition coils. During this, make sure ignition coils are securely seated.

Continued for all vehicles

z

Check DTC memory.

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD) .

z

Read readiness code.

See READINESS CODE .

If the DTC memory has been erased or the Engine Control Module separated from permanent (battery)
positive, the readiness code must be generated again.

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD) .

VALVE GEAR, SERVICING

1. 10 N.m

2. Intake camshaft

z

Checking axial clearance. See Checking Camshaft Axial Clearance

z

Removing and installing. See VALVE GEAR, SERVICING

Checking radial clearance with plastigage:

z

Wear limit: 0.1 mm

z

Run-out: max. 0.01 mm

3. Drive chain

z

Before removing mark direction of rotation (installation position). See CAMSHAFT,
REMOVING AND INSTALLING

NOTE:

z

Cylinder heads which have cracks between the valve seats or between
valve seat inserts and the spark plug thread can be used further without
reducing service life, provided the cracks do not exceed a maximum of 0.3
mm in width, or when no more than the first four spark plug threads are
cracked.

z

After installing new hydraulic lifters, the engine must not be started for
approx. 30 minutes (otherwise valves will strike pistons), then turn
crankshaft two rotations.

NOTE:

The following list refers to items in Fig. 92 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



4. 10 N.m

5. O-ring

z

Always replace

z

Only for engine codes: AWP, AWV

6. Camshaft adjustment valve (N205)

z

Only for engine codes: AWP, AWV

z

Check camshaft adjustment. See CAMSHAFT ADJUSTMENT, CHECKING .

7. 3 N.m

z

Only for engine codes: AWP, AWV

8. Camshaft adjuster

z

Only for engine codes: AWP, AWV

z

For vehicles with engine code: APH; Chain tensioner

z

Secure with 3366 before removing. See CAMSHAFT, REMOVING AND INSTALLING .

z

Seal transition of hydraulic chain tensioner/cylinder head. See Sealing transition points
between chain tensioner/cylinder head


z

Check camshaft adjustment. See CAMSHAFT ADJUSTMENT, CHECKING .

9. Gasket

z

Rubber/metal seal

z

Replace

10. Cylinder head

z

Removing and installing. See CYLINDER HEAD, REMOVING AND INSTALLING .

z

Refacing valve seats. See VALVE SEATS, REFACING .

z

Reworking sealing surface. See Reworking Cylinder Head Sealing Surface .

z

Sealing transition points. See Sealing transition points between double bearing cap and
cylinder head
 and Sealing transition points between chain tensioner/cylinder head .

11. Valves

z

Do not rework only grinding-in is permitted

z

Valve dimensions. See Valve Dimensions .

z

Sodium-filled exhaust valves: Observe disposal instructions. See VALVE SEATS, REFACING

12. Oil seal

z

Replacing. See CAMSHAFT OIL SEAL, REPLACING .

13. Hood

z

For Camshaft Position (CMP) sensor

z

When installing note fixing arrangement

14. Washer

z

Conical

15. 25 N.m

16. Camshaft Position (CMP) sensor -G40-



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



See CHECK CAMSHAFT POSITION (CMP) SENSOR .

17. 10 N.m

18. 65 N.m

z

Use counter-hold 3036 to loosen and tighten

19. Camshaft sprocket

z

Note installation position: small web of camshaft sprocket points outward and No. 1 Cyl. TDC
marking is visible

z

Note position when installing toothed belt. See TOOTHED BELT, REMOVING, INSTALLING
AND TENSIONING
 .

20. Oil seal

z

Replacing. See CAMSHAFT OIL SEAL, REPLACING .

21. Valve guide

z

Checking. See VALVE GUIDES, CHECKING .

22. Valve stem seal

z

Replacing. See VALVE STEM SEALS, REPLACING .

23. Valve spring

z

Removing and installing: remove cylinder head with 3362

z

Installing. See VALVE STEM SEALS, REPLACING .

24. Upper valve spring plate

25. Valve keepers

26. Hydraulic lifter

z

Do not interchange

z

With hydraulic valve clearance compensation

z

Checking. See HYDRAULIC LIFTERS, CHECKING

z

Store with cam contact surface downward

z

Before installing check camshaft axial clearance. See Checking Camshaft Axial Clearance .

z

Oil contact surface

27. Intake camshaft bearing cap

z

Installation position and installation sequence. See CAMSHAFT, REMOVING AND
INSTALLING
 .

28. Double bearing cap

z

Lightly coat bearing cap contact surface with sealant AMV 174 004 01

z

Must sit on alignment bushing

z

Seal transitions of double-bearing cap/cylinder head. See Sealing transition points between
double bearing cap and cylinder head
 .

29. Exhaust camshaft bearing cap

z

Installation position and installation sequence. See CAMSHAFT, REMOVING AND
INSTALLING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
