z VAG 1332 Torque wrench (40-200 N.m) z VAG 1921 Hose clip pliers z 3070 Installation tool with guide pins z VAS 5024 Assembly tool for spring-type clamps Fig. 80: Identifying Special Tools And Equipment Engines with Polydrive cylinder head bolts: z 3452 Tool Requirements z The engine must be no more than warm to touch Work sequence z Note safety precautions before starting work. See SAFETY PRECAUTIONS WHEN WORKING ON z Observe rules for cleanliness. See RULES OF CLEANLINESS . z Check whether a coded radio is installed. If so, obtain anti-theft coding. z With ignition switched off, disconnect battery Ground strap. z Remove engine cover. z Drain coolant. See COOLING SYSTEM, DRAINING AND FILLING . z Remove secondary air pump motor and bracket. WARNING: Fuel supply lines are under pressure! Before removing from hose
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
|
