Volkswagen New Beetle. Manual - part 1099





Installing

z

Place a clean cloth in cylinders so that no dirt or emery cloth particles can get in between cylinder wall
and piston. Also prevent dirt and emery cloth particles from getting into coolant

z

Carefully clean cylinder head and cylinder block sealing surfaces. Ensure that no scoring or scratches are
formed (when using abrasive paper the grade must not be less than 100).

z

Carefully remove metal particles, emery remains and cloths.

z

Turn crankshaft to TDC No. 1 cylinder.

Fig. 86: Turning Crankshaft To TDC Of No. 1 Cylinder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft back slightly.

z

Loosen bolts 1 and 2 at bracket for turbocharger approx. 2 revolutions in order to avoid tension when
installing cylinder head.

NOTE:

z

There must be no oil or coolant in the cylinder head bolt pockets in the
cylinder head.

z

Only remove the new cylinder head gasket from its packing immediately
before installing.

z

Handle the new gasket with extreme care. Damaging will lead to leaks.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 87: Loosening Bolts 1 And 2 At Bracket For Turbocharger
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Center screw guide pins from 3070 into holes for cylinder head bolts 8 and 10.

Fig. 88: Installing Cylinder Head Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install new cylinder head gasket. Lettering (Part No.) must be readable.

z

Install cylinder head, screw in 8 remaining cylinder head bolts and tighten by hand.

z

Remove guide pins with removal tool from 3070. To do this turn removal tool counterclockwise, until
pins are free.

z

Install remaining cylinder head bolts and tighten hand-tight.

z

Tighten cylinder head in tightening sequence as follows:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 89: Cylinder Head Bolt Tightening Sequence
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pretighten all bolts to 40 N.m.

z

Then tighten all bolts 1/4 turn (90°) further using a rigid wrench.

z

Then tighten all bolts again 1/4 turn (90°) further.

z

Install gasket between turbocharger/exhaust manifold and bolt turbocharger as well as bracket to cylinder
head.

z

Install toothed belt and adjust valve timing. See TOOTHED BELT, REMOVING, INSTALLING
AND TENSIONING
 .

Filling with new coolant. See COOLING SYSTEM, DRAINING AND FILLING .

The rest of the assembly is basically a reverse of the disassembling sequence.

z

Perform work sequence "Procedure after voltage supply open circuit".

For engine code APH see PROCEDURE AFTER CORRECTING VOLTAGE SUPPLY OPEN
CIRCUIT
 . For engine codes AWP and AWV, see PROCEDURE AFTER CORRECTING
VOLTAGE SUPPLY OPEN CIRCUIT
 .

z

Check DTC memory.

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD) .

z

Read readiness code.

See READINESS CODE .

NOTE:

There is no requirement to retighten the cylinder head bolts after repairs.
