Checking ring to groove clearance. See Checking Ring To Groove Clearance

z

2 or 3 part oil scraper ring, mixed installations permissible

2. Piston

z

Checking. See Checking Piston

z

Mark installation position and cylinder number

z

Arrow on piston crown points to pulley end

z

Install using piston ring clamp

3. Connecting rod

z

Only replace as a set

z

Mark cylinder number -B-

z

Installation position: Marking -A- faces toward pulley end

4. Connecting rod bearing cap

z

Note installation position

z

Installation position: Marking -A- faces towards pulley end

z

Mark cylinder number -B-

5. 30 N.m + 1/4 turn (90°) further

z

Always replace

z

Oil threads and contact surface

z

To measure radial clearance tighten to 30 N.m but not further

6. Pressure relief valve, 27 N.m

z

Opening pressure: 1.3 to 1.6 bar

7. Oil spray jet

z

For piston cooling

8. Bearing shell

z

Note installation position

z

Do not interchange used bearing shells

z

Ensure retaining lugs fit tightly in recesses

z

Axial clearance New: 0.10-0.31 mm Wear limit: 0.40 mm

Check radial clearance with Plastigage:

z

New: 0.01-0.05 mm

z

Wear limit: 0.09 mm

z

Do not rotate crankshaft when checking radial clearance

9. Cylinder block

z

Checking cylinder bores. See Checking Cylinder Bores

z

Piston and cylinder dimensions. See PISTON AND CYLINDER DIMENSIONS (ENGINE
CODE: APH)




2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



10. Connecting rod bolt

z

Always replace

11. Circlip

12. Piston pin

z

If difficult to remove, heat piston to 60° C

z

Remove and install with VW 222a

Fig. 67: Exploded View Of Pistons And Connecting Rods (Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Piston Ring Gap

Fig. 68: Checking Piston Ring End Gap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Feeler gauges



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Push ring squarely from above down to approx. 15 mm from bottom end of cylinder.

PISTON RING END GAP (ENGINE CODE APH)

Checking Ring To Groove Clearance

Fig. 69: Checking Ring To Groove Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Feeler gauges

z

Clean groove before check.

PISTON RING-TO-GROOVE CLEARANCE (ENGINE CODE APH)

Checking Piston

Special tools and equipment

z

Micrometer 75-100 mm

z

Measure pistons approx. 10 mm from lower edge of skirt, at 90° to piston pin axis.

Piston ring

Gap

New

Wear limit

Compression mm rings

0.15-0.40

0.8

Oil scraper ring mm

0.25-0.50

1.0



Clearance

Piston ring

New

Wear limit

Compression rings mm

0.02-0.07

0.12

Oil scraper ring mm

0.02-0.06

0.12



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Deviation from nominal dimension max.: 0.04 mm

Fig. 70: Checking Piston Skirt Diameter
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Cylinder Bores

Special tools and equipment

z

Internal dial indicator 50-100 mm

z

Measure bores at 3 locations in both directions -A- across engine and -B- in line with crankshaft.

Deviation from nominal dimension max.: 0.10 mm

NOTE:

Measuring the cylinder bores must not be done when the cylinder block is
mounted on a repair stand with adapter bracket VW 540, as incorrect
measurements would then be possible.
