Fig. 57: Applying Silicone Sealing Compound To Clean Oil Pan Sealing Surface Thickness of sealant bead -arrows-: 2 - 3 mm z Apply silicone sealant bead as shown to clean sealing surface of sealing flange. Fig. 58: Applying Silicone Sealant Bead To Clean Sealing Surface Of Sealing Flange z Install sealing flange immediately and lightly tighten all bolts. z Tighten sealing flange securing bolts using alternate sequence. Tightening torque: 15 N.m z Remove excess sealant. z Install oil pan. See OIL PAN, REMOVING AND INSTALLING . z Install crankshaft toothed belt sprocket and hold with counter-hold tool 3099. NOTE: The sealing compound bead must not be thicker, otherwise excessive NOTE: Use guide sleeve from 2080A to install sealing flange with the oil seal NOTE: After installing, the sealant must be allowed to dry for approx. 30 minutes
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
|
