Volkswagen New Beetle. Manual - part 1091





1. 90 N.m + 1/4 turn (90°) further

z

Always replace

z

Counter-hold with 3099 to loosen and tighten

z

Threads and shoulder must be free of oil and grease

z

When bolting on, place two washers between toothed belt pulley and counter-hold

2. Crankshaft toothed belt sprocket

3. 15 N.m

4. Oil seal

z

Replacing. See CRANKSHAFT OIL SEAL (BELT PULLEY END), REPLACING

5. Sealing flange

z

Must be located on dowel sleeves

z

Removing and installing. See FRONT SEALING FLANGE, REMOVING AND INSTALLING

6. Cylinder block

z

Removing and installing crankshaft. See CRANKSHAFT, REMOVING AND INSTALLING

z

Disassembling and assembling pistons and connecting rods. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING


7. 60 N.m + 1/4 turn (90°) further

z

Always replace

8. Flywheel/drive plate

z

To remove and install flywheel counter-hold with 3067

z

Removing and installing drive plate. See DRIVE PLATE, REMOVING AND INSTALLING

9. Intermediate plate

z

Must be located on dowel sleeves

z

Do not damage/bend when assembling

10. Sealing flange with oil seal

z

Only replace complete

z

Remove oil pan to be able to remove and install. See OIL PAN, REMOVING AND
INSTALLING


z

Install new sealing flange with fitting sleeve (before installing do not pull sealing sleeve out of oil
seal)

z

Before installing, remove oil residue from crankshaft journal using a clean cloth

z

Do not additionally oil or grease the oil seal sealing lip

z

Use protective sleeve supplied when installing

For 02J, see CLUTCH ASSEMBLY

For 02M, see CLUTCH ASSEMBLY

NOTE:

The following list refers to items in Fig. 46 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Remove protective sleeve first after sealing flange has been slid onto crankshaft journal

z

Install new sealing flange with fitting sleeve (before installing do not pull sealing sleeve out of oil
seal)

Fig. 46: Identifying Front And Rear Sealing Flanges And Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Crankshaft oil seal (belt pulley end), replacing

Special tools and equipment

z

3099 Counter-hold tool

z

VAG 1331 Torque wrench (5-50 N.m)

z

VAG 1332 Torque wrench (40-200 N.m)

z

3203 Oil seal extractor

z

2080 A Fitting sleeve

z

3265 Fitting sleeve



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 47: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove ribbed belt and tensioning element. See RIBBED BELT TENSIONER, REMOVING AND
INSTALLING
 .

z

Remove toothed belt. See REMOVING .

z

Remove crankshaft toothed belt sprocket. To do this counter-hold sprocket with 3099.

Fig. 48: Removing Crankshaft Toothed Belt Sprocket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To guide seal extractor, screw center bolt into crankshaft onto stop by hand.

NOTE:

When bolting on counter-hold place two washers between toothed belt
pulley and counter-hold.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 49: Screwing Center Bolt Into Crankshaft Onto Stop By Hand
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew inner part of oil seal extractor 3203 nine turns (approx. 20 mm) out of outer part and lock with
knurled screw.

z

Lubricate threaded head of oil seal extractor 3203, place it in position and exerting firm pressure screw it
as far as possible into oil seal.

Fig. 50: Lubricating Threaded Head Of Oil Seal Extractor 3203 And Placing In Position And
Exerting Firm Pressure Screw

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen knurled screw and turn inner part against crankshaft until the oil seal is pulled out.

Installing

NOTE:

Gradual introduction of PTFE oil seal (identifying characteristics: no annular
spring, sealing lip wider). The sealing lip of this oil ring must not be oiled or
lubricated. A plain encased seal of older construction (with annular spring) may



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
