Volkswagen New Beetle. Manual - part 1089





Fig. 33: Removing Air Duct To Charge Air Cooler At Bottom Right Of Long Member
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

Engine installed:

z

Turn crankshaft to TDC No.1 cylinder (vehicles with manual transmission).

Fig. 34: Turning Crankshaft To TDC No.1 Cylinder (Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to TDC No.1 cylinder (vehicles with automatic transmission).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 35: Turning Crankshaft To TDC No.1 Cylinder (Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

With engine removed:

z

Turn vibration damper to TDC No. 1 cylinder -arrows-.

Fig. 36: Turning Vibration Damper To TDC No. 1 Cylinder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove coolant expansion tank and place to side.

z

Pull off vacuum pipes at EVAP canister and at throttle valve housing.

z

Remove toothed belt guard (upper part).

z

Install engine support bracket 10-222A with legs 10-222A/1.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 37: Installing Engine Support Bracket 10-222A With Legs 10-222A/1
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Locate bracket 3180 in lifting eye on cylinder head and take-up weight of engine.

z

Remove securing bolts from assembly mount/engine mount, assembly mount/body and assembly
mount/body mount -arrows- and remove assembly mount complete.

Fig. 38: Assembly Mount/Body Mount Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove vibration damper/belt pulley.

z

Remove lower and center toothed belt guard.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 39: Removing Vibration Damper/Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine bracket from cylinder block.

Fig. 40: Removing Engine Bracket From Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mark direction of rotation of toothed belt.

z

Screw tensioning bolt T10092 into toothed belt tensioning element.

NOTE:

When loosening the front engine mount bolt the engine must be raised
slightly with the support bracket.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
