Volkswagen New Beetle. Manual - part 1087





PART I

1. 25 N.m

2. Tensioning device for ribbed belt

z

Turn with open-end spanner to loosen ribbed belt. See RIBBED BELT TENSIONER,
REMOVING AND INSTALLING


3. Toothed belt guard - upper part

4. Toothed belt guard - center section

5. 27 N.m

6. Idler wheel

7. Tensioning roller

8. Toothed belt

z

Mark direction of travel before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELT, REMOVING, INSTALLING
AND TENSIONING


9. Coolant pump

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING

10. O-Ring

z

Always replace if damaged

Fig. 24: Disassembling And Assembling Engine
Courtesy of VOLKSWAGEN OF AMERICA, INC.

II. See PART II

NOTE:

The following list refers to items in Fig. 25 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



11. 15 N.m

12. Tensioner for toothed belt

13. Crankshaft toothed belt sprocket

14. 15 N.m

15. 20 N.m

16. 90 N.m + 1/4 turn (90°) further

z

Always replace

z

Counter-hold with 3099 to loosen and tighten

z

When bolting on, place two washers between toothed belt pulley and counter-hold

17. Toothed belt guard - lower part

18. 10 N.m

z

Insert with locking fluid D 000 600 A2

19. Pulley

z

For power assisted steering pump

20. 25 N.m

21. Ribbed belt

z

Mark direction of rotation before removing

z

Removing and installing. See RIBBED BELT TENSIONER, REMOVING AND
INSTALLING


22. 25 N.m

23. Belt pulley/vibration damper

z

Can only be installed in one position (holes are offset)

z

Note position when installing toothed belt TOOTHED BELT, REMOVING, INSTALLING
AND TENSIONING


Fig. 25: Exploded View Of Engine (Front Engine Components - Part I
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



PART II

Fig. 26: Exploded View Of Engine (Cylinder Block Components) - Part II
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Knock sensor 1 -G61-

z

Checking:

See DTC MEMORY OF MOTRONIC ENGINE CONTROL MODULE, CHECKING AND
ERASING


2. 20 N.m

z

Tightening torque influences function of knock sensor

3. Knock sensor 2 -G66-

z

Checking:

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD)

4. Dipstick

z

Oil level must not be above the max. mark!

5. Guide

z

For dipstick

6. O-Ring

z

Always replace

7. Coolant pipe

8. 20 N.m

9. Oil filter bracket

NOTE:

The following list refers to items in Fig. 26 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Disassembling and assembling. See PART II

10. 15 N.m + 1/4 turn (90°) further

z

Always replace

11. Oil cooler

z

Coat contact area to flange, outside the seal, with AMV188 100 02

z

Ensure clearance to adjacent components

z

Note. See ENGINE, DISASSEMBLING AND ASSEMBLING

12. 25 N.m

13. Oil filter

z

Loosen with strap wrench

z

Tighten by hand

z

Note instructions on filter when installing

14. Gasket

z

Always replace

15. 10 N.m

16. Engine speed sender

z

Checking:

See GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD)

17. Connection

18. 15 N.m

19. O-Ring

z

Always replace

20. Coolant thermostat

z

Checking: heat-up thermostat in water

z

Opening commences approx. 86°C

z

Opening lift min. 7 mm

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING

z

Observe installation position. See THERMOSTAT, REMOVING AND INSTALLING

z

Checking: heat-up thermostat in water

21. 45 N.m

22. Compact bracket

z

For ribbed belt tensioning roller, alternator, power steering pump and air conditioning compressor

23. Right engine bracket

Ribbed belt tensioner, removing and installing
