Volkswagen New Beetle. Manual - part 1090





Fig. 41: Screwing Tensioning Bolt T10092 Into Toothed Belt Tensioning Element
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align pressure piston using pointed pliers or wire before tensioning (hole in pressure piston must align
with hole in housing).

z

Tension piston of tensioning element just enough that the piston can be locked with locking pin T40011.

z

Remove toothed belt.

z

Turn crankshaft back slightly.

Installing

A - Toothed belt completely removed

If toothed belt has only been removed from camshaft. See B - TOOTHED BELT ONLY TAKEN OFF
CAMSHAFT SPROCKET
 .

Conditions

z

The pistons must not be positioned at TDC

Work sequence

z

Bring mark on camshaft in line with the mark on cylinder head cover.

NOTE:

When turning the camshaft the crankshaft must not be at TDC (danger of
damage valves/piston crown).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 42: Aligning Mark On Camshaft With The Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place toothed belt on crankshaft sprocket (observe direction of rotation).

z

Install engine mount to cylinder block.

Tightening torque: 45 N.m

z

Install lower part of toothed belt guard. Insert securing bolts with locking fluid "D 000 600 A2".

Tightening torque: 10 N.m

z

Secure vibration damper/belt pulley with one bolt (note fixing arrangement).

z

Turn crankshaft to TDC No. 1 cylinder.

Fig. 43: Turning Crankshaft To TDC No. 1 Cylinder

NOTE:

Before installing engine mount, insert bolts into mount.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install toothed belt onto coolant pump, tensioning roller and camshaft sprocket.

z

Tighten toothed belt. See TENSIONING TOOTHED BELT .

B - Toothed belt only taken off camshaft sprocket

z

Bring mark on camshaft in line with the mark on cylinder head cover.

Fig. 44: Aligning Mark On Camshaft With The Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to TDC No. 1 cylinder.

z

Install toothed belt onto camshaft sprocket.

z

Tighten toothed belt. See TENSIONING TOOTHED BELT

Tensioning toothed belt

z

Tension toothed belt by pulling out locking pin T40011 and removing tensioning bolt T10092.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 45: Tensioning Toothed Belt By Pulling Out Locking Pin T40011 And Removing Tensioning
Bolt T10092

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft two full turns and check whether camshaft and crankshaft marks align with their
reference points.

z

Install vibration damper/belt pulley

Tightening torque: 25 N.m

z

Install center part of toothed belt guard. (Insert securing bolts with locking fluid D 000 600 A2).

Tightening torque: 10 N.m

z

Install upper toothed belt guard.

z

Install aggregate mount and engine mount. Tightening torque. See ENGINE/TRANSMISSION
MOUNTS
 .

z

Install ribbed belt tensioner.

Tightening torque: 25 N.m

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Install air duct to charge air cooler at bottom right of long member.

z

Install right-hand insulation tray

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

SEALING FLANGES AND DRIVE PLATE, REMOVING AND INSTALLING

NOTE:

For repairs to the clutch:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
