Fig. 64: Removing Drive Plate And Shim z Tighten bolts to 60 N.m and turn 90° (1/4 turn) further (turning further can be done in several stages). CRANKSHAFT, REMOVING AND INSTALLING 1. Oil pump z With pressure relieve valve of 12 bar z Before installing, check that both dowel sleeves for centering oil pump/cylinder head are installed z Removing and installing. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND 2. 15 N.m 3. Chain sprocket z For oil pump drive z Check for wear 4. Bearing caps 1, 2, 4 and 5 z For bearing cap without oil groove z For cylinder block with oil groove z Do not interchange used bearing shells (mark) NOTE: z Before removing the crankshaft, prepare a suitable surface so that the z When stripping and assembling the engine it should be secured to the NOTE: The following list refers to items in Fig. 65 .
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
|
