Volkswagen New Beetle. Manual - part 1076





1. Rubber grommet

z

located in cylinder block

2. Spreader rivet

3. Spreader rivet

z

to remove oil sump protection push upward

z

to install press in flush

4. Socket

5. Bolt, 37 N.m

z

secure in cylinder block

z

clean threads before installing

z

install with locking compound D 000 600 A2

6. Oil sump protection

Fig. 138: Exploded View Of Oil Sump Protection Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part II (Oil filter housing, disassembling and assembling)

1. Sealing plug, 40 N.m

z

Replace

2. Seal

z

Installed firmly on item -1-

3. Spring

z

For pressure relief valve, approx. 4 bar

4. Piston

z

For pressure relief valve, approx. 4 bar

NOTE:

The following list refers to items in Fig. 139 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



5. Seal

z

Replace

6. Non-return valve, 8 N.m

z

Various versions: bolted or pressed

z

Press fit valves are not available as spare parts

7. Seal

z

Slide on up to shoulder of sealing cover item - 8 -

z

Replace if damaged

8. Cover

9. Retaining clip

10. Sealing plug, 15 N.m

11. Seal

z

If sealing ring is leaking cut open and replace.

12. 1.4 bar oil pressure switch -F1-, 25 N.m

z

Black

z

Checking. See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING

13. Seal

z

If sealing ring is leaking cut open and replace.

14. Oil filter bracket

z

With pressed in non-return valve

15. 15 N.m + 1/4 turn (90°) further

z

Replace

16. Seal

z

Replace

z

Clip into lugs on oil cooler

17. Oil cooler

z

Coat contact surfaces to oil filter bracket outside seal with AMV 188 100 02

z

Ensure clearance to adjacent components

z

See note. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND
INSTALLING
 .

18. 25 N.m

19. Oil filter

z

Loosen with filter strap or oil filter key 3417

z

Tighten by hand

z

Note instructions on filter when installing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 139: Exploded View Of Oil Filter Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil pump, removing and installing (Engine codes AEG, AVH, AZG, BEV)

Removing

z

Remove sump and baffle plate. See OIL SUMP, REMOVING AND INSTALLING .

z

Unscrew bolt -2-.

z

Pull off chain sprocket from oil pump shaft.

z

Unscrew bolts -1- and -3- and remove oil pump.

Fig. 140: Removing And Installing Oil Pump (Engine codes AEG, AVH, AZG, BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order. Note the following:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Dowel sleeves. See Fig. 132 , item 8 above oil pump.

z

Installed position of oil pump shaft/chain sprocket: Can only be installed in one position.

Installing sump and baffle plate. See OIL SUMP, REMOVING AND INSTALLING

Tightening torques. See Part I (Engine codes AEG, AVH, AZG)

Oil pump with balancer shaft gear assembly, disassembling and assembling (Engine codes BDC, BGD)

1. Chain guard

2. Chain

z

Mark direction of rotation before removing (installation position)

3. Dowel sleeves

4. Oil pump with balancer shaft gear assembly

z

Before installing, check that both dowel sleeves for centralizing are installed

5. 3 N.m

z

Insert with locking compound D 000 600 A2

6. Cover

z

Prevents engine oil foaming

7. Oil return union

z

With seal/gasket

8. 9 N.m

9. Suction line

z

Clean strainer if soiled

10. 8 N.m

11. O-ring

z

Replace

12. 15 N.m + 1/4 turn (90°) further

z

Observe different lengths of bolts. See Fig. 137

13. O-ring

z

Replace

14. Sealing plug, 15 N.m + 1/4 turn (90°) further

15. Dowel sleeves

16. Outer rotor

z

Check running surfaces for scoring

z

Marking(s) must be visible

NOTE:

The following list refers to items in Fig. 141 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
