Volkswagen New Beetle. Manual - part 1075





z

For engine codes AEG, AVH, AZG. See Part I (Engine codes AEG, AVH, AZG)

z

For engine codes BDC, BGD. See Part I (Engine codes BDC, BGD) .

1. 15 N.m

2. Sealing flange

z

Must be located on dowel sleeves

z

Insert with silicone sealant D 176 404 A2. See FRONT SEALING FLANGE, REMOVING
AND INSTALLING


z

Removing and installing. See FRONT SEALING FLANGE, REMOVING AND INSTALLING

z

Replacing crankshaft oil seal, poly V-belt pulley end. See CRANKSHAFT OIL SEAL -
PULLEY END, REPLACING


3. Pressure relief valve, 27 N.m

4. Oil spray jet

z

For piston cooling

5. Dipstick

z

Oil level must not exceed max. mark!

z

Markings. See Fig. 135

6. Dipstick guide

z

Fastened to intake manifold

z

Pull off to extract oil

7. Guide tube

8. Dowel sleeves

9. O-ring

z

Replace

10. 15 N.m

11. Suction line

z

Observe part number

z

Clean strainer if soiled

12. Baffle plate

13. Oil sump upper part

z

Clean sealing surface before installing

z

Insert with silicone sealant D 176 404 A2. See OIL SUMP, REMOVING AND INSTALLING

z

Removing and installing. See OIL SUMP, REMOVING AND INSTALLING

z

Sell as a set with oil sump lower part protection. For latest oil sump part number:

See Parts catalog

NOTE:

The following list refers to items in Fig. 134 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



14. 15 N.m

15. 22 N.m

16. Oil sump lower part protection

z

Clean sealing surface before installing

z

Insert with silicone sealant D 176 501 A1. See ENGINE CODE BEV

17. Sealing ring

z

Replace

18. Oil drain plug, 30 N.m

z

Replace if leaking. See Parts catalog for correct application. In some cases seal and drain plug are
combined; do not interchange with separate seal and drain plug.

19. 10 N.m

20. Oil pump

z

With pressure relief valve of 12 bar

z

Before installing, check that both dowel sleeves for centralizing oil pump/cylinder block are
installed

z

Replace if running surfaces and gears are scored

z

Removing and installing. See Oil pump, removing and installing (Engine codes AEG, AVH,
AZG, BEV)


21. Chain sprocket

z

Observe installing position

22. Chain

23. 20 N.m

z

Use counter support T10051 to loosen and tighten

24. Chain tensioner with tensioning rail, 15 N.m

z

When installing, pretension spring and fit

Fig. 134: Exploded View Of Lubrication System Components (Engine Code BEV)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dipstick Marks (Engine codes AEG, AVH, AZG, BEV)

1. max. mark

2. min. mark

a. Area above hatched field up to max. mark: Do not add engine oil!

b. Oil level within hatched field: Engine oil may be added

c. Area from min. mark up to hatched field: Add max. 0.5L. of engine oil!

Fig. 135: Identifying Dipstick Marks (Engine Codes AEG, AVH, AZG, BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

(Dipstick Marks) Engine codes BDC, BGD

1. max. mark

2. Min. mark

a. Area above hatched field up to max. mark: Do not add engine oil!

b. Oil level within hatched field: Engine oil may be added

c. Area from min. mark up to hatched field: Add max. 0.5L. of engine oil!

NOTE:

The following list refers to items in Fig. 135 .

NOTE:

The following list refers to items in Fig. 136 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 136: Identifying Dipstick Marks (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Bolt allocation for balancer shaft gear assembly (Engine codes BDC, BGD)

A. M7 x 40 hex bolt

B. M7 x 55 hex bolt

C. M7 x 90 hex bolt

D. Sealing plug with O-ring

Fig. 137: Identifying Bolt Allocation For Balancer Shaft Gear Assembly (Engine codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 138 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
