Wear limit: max. 0.15 mm

Installed position of camshaft bearing caps

Fig. 104: Identifying Installed Position Of Camshaft Bearing Caps
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Note offset. Before installing camshaft fit bearing caps and determine installed position.

Valve dimensions

Fig. 105: Identifying Valve Dimensions
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code AEG

VALVE DIMENSIONS SPECIFICATIONS (ENGINE CODE AEG)

NOTE:

Valves must not be reworked. Only lapping is permitted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Engine codes AVH, AZG, BDC, BEV, BGD

VALVE DIMENSIONS SPECIFICATIONS (ENGINE CODES AVH, AZG, BDC, BEV, BGD)

Valve seats, reworking

Special tools, testers, measuring instruments and auxiliary items required

z

Depth gauge

z

Valve seat refacing tool

Calculating maximum permissible reworking dimension

z

Insert valve and press firmly against seat.

z

Measure distance -a- between end of valve stem and upper edge of cylinder head.

Dimension

Intake valve

Exhaust valve

Dia. a -

39.5 +/- 0.15

32.9 +/- 0.15

Dia. b - mm

6.92 + 0.02

6.92 + 0.02

Length c - mm

91.85

91.15

Angle a - degrees

45

45

Dimension

Intake valve

Exhaust valve

Dia. a - mm

39.5 +/- 0.15

32.9 +/- 0.15

Dia. b - mm

6.98 +/- 0.007

6.96 +/- 0.007

Length c - mm


91.85

91.15

Angle a - degrees

45

45

NOTE:

z

When repairing engines with leaking valves, it is not sufficient to
rework or replace valve seats and valves. It is also necessary to
check the valve guides for wear. This particularly important on high
mileage engines.

z

The valve seats should only be reworked just enough to produce a
perfect seating pattern. The maximum permissible reworking
dimension must be calculated before reworking commences. If the
reworking dimension is exceeded, the function of the hydraulic lifters
can no longer be guaranteed and the cylinder head should be
replaced.

NOTE:

If the valve is to be replaced as part of a repair, use a new valve for the
measuring.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 106: Measuring Distance Between End Of Valve Stem And Upper Edge Of Cylinder Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Calculate maximum permissible reworking dimension from measured distance -a- and minimum
dimension.

Minimum dimensions:

Intake valve 33.8 mm

Exhaust valve 34.1 mm

Measured distance -a- minus minimum dimension = maximum permissible reworking dimension.

Example:

CALCULATING MAXIMUM PERMISSIBLE REWORKING DIMENSION (EXAMPLE)

Reworking intake valve seat

INTAKE VALVE SEAT DIMENSION SPECIFICATIONS

Measured distance -a-

35.1 mm

Minimum dimension - 34.1


mm

= max. perm. Rework dimension

(1)

1.0 mm

(1)

The maximum permissible reworking dimension is shown as dimension "b" in illustrations for
reworking of valve seats.

Dimension

Intake valve seat

Dia. a - mm

39.2

b - mm

max. permissible reworking dimension

c - mm

1.8...2.2



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 107: Reworking Intake Valve Seat
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Reworking exhaust valve seat

EXHAUST VALVE SEAT DIMENSION SPECIFICATIONS

Z

Cylinder head lower edge

45°

Valve seat angle

30°

Upper correction angle

Dimension

Exhaust valve seat

Dia. a - mm

32.4

Dia. b - mm

max. permissible reworking dimension

c - mm

2.2...2.6

Z

Cylinder head lower edge

45°

Valve seat angle

30°

Upper correction angle



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
