Volkswagen New Beetle. Manual - part 1070





Fig. 108: Reworking Exhaust Valve Seat
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Camshaft oil seal, replacing

For coil spring seals:

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

10-203 Puller

z

2085 Oil seal extractor

z

3415 Counterhold

z

V.A.G1331 Torque wrench (5 ... 50 N.m)

z

V.A.G 1332 Torque wrench (40 ... 200 N.m)

Fig. 109: Identifying Special Tools (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

For PTFE seals:

z

2085 Oil seal extractor

z

3415 Counter support

z

T10071 Puller

z

V.A.G 1331 Torque wrench (5..50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 110: Identifying Special Tools (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove toothed belt guard, upper part.

z

Set camshaft pulley to TDC No. 1 cylinder by turning crankshaft.

Fig. 111: Aligning Mark On Camshaft Sprocket With Arrow On Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Mark on camshaft sprocket must align with arrow on toothed belt guard

z

Release tensioning roller and take toothed belt off camshaft pulley.

z

Turn crankshaft back slightly.

z

Remove camshaft pulley. To loosen camshaft pulley securing bolt, hold pulley with counter support 3415



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 112: Removing Camshaft Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove woodruff key from camshaft.

z

Screw camshaft pulley securing bolt fully into camshaft onto limit stop.

z

Unscrew inner part of oil seal extractor 2085 two turns (approx. 3 mm) out of outer part and lock in
position with knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and exerting firm pressure screw it into
oil seal as far as possible.

Fig. 113: Removing Camshaft Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen knurled screw and turn inner part of extractor against camshaft until oil seal has been extracted.

z

Clamp flats of oil seal extractor in a vice. Remove oil seal with pliers.

Installing

Requirements



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Pistons must NOT be positioned at TDC.

Fig. 114: Identifying Oil Seals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PTFE sealing rings

z

Position oil seal with guide sleeve T10071 and press in onto limit stop with press sleeve T10071/1 and
bolt T10071/2.

Coil spring seals

z

Position oil seal with guide sleeve 10-203 and press in onto limit stop with press sleeve and bolt from 10-
203.

NOTE:

A PTFE seal (Teflon) -2 is gradually being introduced instead of the inner
coil spring seal -1-. This has a wider sealing lip. PTFE oil seals are
installed free of oil and grease. A radial shaft seal of older design (with coil
spring) may be replaced with a PTFE oil seal, but not vice versa. When a
PTFE oil seal is installed, then only such an oil seal may be installed as a
replacement part!

NOTE:

Do not additionally oil or grease the oil seal sealing lip.

NOTE:

Oil or grease lightly the oil seal sealing lip.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
