Only engine codes BDC, BGD

z

The balancer shaft gear assembly must be adjusted. See OIL PUMP WITH BALANCER SHAFT
GEAR ASSEMBLY, REMOVING AND INSTALLING .

crankshaft or conrod bearings. Perform the following work sequences to
prevent consequential damage once repairs are complete:

z

Thoroughly clean oil passages

z

Replace oil spray jets

z

Replace oil cooler

z

Replace oil filter



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 21: Disassembling And Assembling Engine (Parts I & II)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



I. See PART I

II. See PART II

Part I

1. 45 N.m

2. Engine bracket

3. 25 N.m

4. Retainer

z

According to engine versions

5. Retainer

z

According to engine versions

6. Clamp

7. 10 N.m

z

For engine cover

z

According to engine versions

8. 20 N.m

z

According to engine versions

9. Toothed belt guard-upper part

10. Toothed belt guard, center section

11. 20 N.m

12. Washer

13. Tensioner

z

Checking semiautomatic toothed belt tensioning roller. See SEMI-AUTOMATIC TOOTHED
BELT TENSIONING ROLLER, CHECKING .

14. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING

15. Rear toothed belt guard

16. Washer

17. O-ring

z

Replace

18. Coolant pump

z

Check for ease of movement

NOTE:

The following list refers to items in Fig. 22 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

If damaged or leaking renew complete

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING .

19. 15 N.m

20. Crankshaft toothed belt sprocket

21. 90 N.m + 1/4 turn (90°) further

z

Replace

z

Threads and shoulder must be free of oil and grease

z

Use counter support tool 3415 to loosen and tighten

22. Toothed belt guard, lower part

23. 10 N.m

z

Replace

24. Clutch

z

For air conditioning compressor

25. Belt pulley

z

For power steering pump

26. Ribbed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing and installing. See RIBBED BELT, REMOVING AND INSTALLING .

27. Belt pulley/vibration damper

z

Can only be installed in one position. Holes are offset

z

Note position when installing toothed (timing) belt. See TOOTHED BELTS, REMOVING,
INSTALLING AND TENSIONING .

28. 25 N.m

29. Tensioning element for ribbed belt

z

Turn with open end wrench to loosen ribbed belt. See RIBBED BELT, REMOVING AND
INSTALLING .
