Volkswagen New Beetle. Manual - part 1043





Fig. 16: Locating Transmission Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.


-c- = 18...20 mm.

Torque settings. See ASSEMBLY MOUNTING , Assembly mountings.

Tightening torques

TORQUE SPECIFICATIONS

Assembly mounting

Tightening torques

Engine mounting

Bolted connections

Torque setting

Bolts, nuts

(1)

M6

10 N.m

M7

15 N.m

M8

25 N.m

M10

40 N.m

M12

60 N.m

Torque converter to drive plate

(2)

Drive (axle) shaft

(3)

(1)

Deviating from above: Engine to transmission connecting bolts. For 02J, see TORQUE
SPECIFICATIONS
 . For 01M A/T, see TORQUE SPECIFICATIONS . For 09G, see TORQUE
SPECIFICATIONS
 .

(2)

For 01M, see DRIVE PLATE . For 09G, see either DRIVE PLATE (1.8L) or DRIVE PLATE
(2.0L)
 .

(3)

See FRONT AXLE SHAFT .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 17: Identifying Engine Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Mounting to body

40 N.m + 90°(1/4 turn)

Replace bolts

2. Mounting/bracket to body

25 N.m

3. Mounting to engine mounting

100 N.m

Transmission mounting

NOTE:

The following list refers to items in Fig. 17 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 18: Identifying Transmission Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Mounting to body

40N.m + 90° (1/4 turn)

Replace bolts

NOTE:

The following list refers to items in Fig. 18 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
