z

Move engine/transmission assembly to a work bench with jack V.A.G 1383 A.

Fig. 12: Moving Engine/Transmission Assembly To Work Bench With Jack
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lower engine/transmission assembly so that transmission is on work bench.

z

Remove engine/transmission connecting bolts.

z

Press off transmission.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Continuation for all models

z

Attach lifting tackle 2024 A as follows and lift off engine/transmission jack V.A.G 1383 A with
workshop crane.

Fig. 13: Attaching Lifting Tackle To Engine Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pulley end: 3rd hole of lifting rail in position 2

Flywheel end: 3rd hole of lifting rail in position 8

CAUTION: Hooks and locating pins must be secured with locking pins.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Secure engine to support clamp VW 313 using engine and transmission bracket VW 540 and
supplementary set VW 540/1B. Dowel sleeves must be removed.

Engine installation notes

Installation is performed in the reverse sequence, Note the following.

z

Insert new dowel sleeves in cylinder block for centralizing engine and transmission.

z

Fit intermediate plate onto sealing flange and slide onto dowel sleeves (arrows).

NOTE:

Positions marked 1...4 on the bar must face toward belt pulley end. The
holes in the hook rails are counted up from the hook.

WARNING:

When performing repair work, especially due to the confined conditions
in the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 14: Fitting Intermediate Plate Onto Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with manual transmission

z

Lightly grease input shaft splines with G 000 100 grease.

z

Check clutch and clutch operating mechanism, then install.

See CLUTCH ASSEMBLY .

z

Install gear shift mechanism, adjust gear shift cables if necessary:

See SELECTOR MECHANISM



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
