1. 20 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

Note sequence when loosening and tightening. See CAMSHAFT, REMOVING AND
INSTALLING
 .

2. Rocker shaft

z

Do not interchange

3. Cylinder head bolt

z

Note sequence when loosening and tightening. See CYLINDER HEAD, REMOVING AND
INSTALLING
 .

z

Before installing, install washers item 4 into cylinder head

4. Washer

z

For cylinder head bolts

z

Install into cylinder head before installing bearing caps

5. Hydraulic lifters

z

Do not interchange.

z

With hydraulic valve clearance compensation.

z

Store with cam contact surface downward.

z

Before installing check camshaft axial clearance. See Checking camshaft axial clearance

z

Oil contact surfaces.

z

Before removing, remove camshaft bearing shells

6. Keepers

7. Valve spring plate

8. Exterior valve spring

z

Removing and installing: Cylinder head

Removed: with 2037

Installed: See VALVE STEM SEALS, REPLACING , Replacing valve stem seals

9. Interior valve spring

z

Removing and installing: Cylinder head

Removed: with 2037

Installed: See VALVE STEM SEALS, REPLACING .

10. Valve stem seal

z

Replacing. See VALVE STEM SEALS, REPLACING

11. Valve guide

z

Checking. See VALVE GUIDES, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

If wear limit is exceeded, replace cylinder head

12. Unit injector

z

Removing and installing. See INJECTOR UNIT, REMOVING AND INSTALLING .

13. Cylinder head

z

See notes under VALVE TRAIN, SERVICING

14. Seal

z

Do not add oil or grease oil seal sealing lip

z

Remove oil residues of camshaft pin with a clean cloth before installing.

z

Seal groove on camshaft taper when installing with commercially available sticky tape (e.g.
Tesafilm)

z

Removing and installing. See OIL SEAL, REMOVING AND INSTALLING

15. Valves

z

Replace valve when scoring can be seen at shaft and contact surfaces

z

Do not rework. Only lapping-in is permitted

z

Valve dimensions. See Fig. 111

16. Bearing shell

z

Do not interchange used bearing shells (mark)

z

Make sure tabs seating correctly in bearing cap and cylinder head

17. Camshaft

z

Checking axial clearance. See Checking camshaft axial clearance

z

Removing and installing. See CAMSHAFT, REMOVING AND INSTALLING

z

Check radial clearance with plastigage

Wear limit: 0.11 mm

z

Run-out: max. 0.04 mm

18. Bearing cap

z

Installation sequence. See CAMSHAFT, REMOVING AND INSTALLING .

z

Install seal bearing cap contact surfaces 1 and 5 with AMV 174 004 01. See Sealing bearing cap
contact surfaces 1 and 5 with AMV 174 004 01


19. 8 N.m plus an additional 1/4 turn (90°)

z

Always replace

Checking camshaft axial clearance



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 109: Checking Camshaft Axial Clearance (End Play)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

Dial gauge

Measure with hydraulic lifters removed and with first, third and last bearing caps installed.

Wear limit: max. 0.15 mm

Sealing bearing cap contact surfaces 1 and 5 with AMV 174 004 01

Fig. 110: Sealing Bearing Cap Contact Surfaces
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply a thin even coat of sealant AMV 17400401 onto surfaces -1-.

Valve dimensions

NOTE:

Observe that no sealant comes into the grooves (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 111: Identifying Valve Dimensions
Courtesy of VOLKSWAGEN OF AMERICA, INC.

VALVE DIMENSIONS

Valve guides, checking

Special tools and equipment

NOTE:

Valves must not be reworked. Only lapping-in is permitted.

Dimensions

Intake valve

Exhaust valve

diameter a (mm)

35.95

31.45

diameter b (mm)

6.980

6.956

length c (mm)

89.95

89.95

contact face angle

45 degrees

45 degrees



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
