3.1 Removing and installing relay carrier on left beneath dash panel Caution When battery -A- is disconnected and reconnected, the pro‐ cedure described in the workshop manual must be strictly observed ⇒ page 4 . Removing ⇒ page 4 . – Remove storage compartment on driver side ⇒ General body repairs, interior; Rep. gr. 68 . – Unscrew bolts -arrows- for bracket. – Pull relays -arrows- out of relay carrier. Note The number of relays depends on the vehicle equipment level. – Unclip locking lugs in direction of -arrow- outwards and then push connectors -1- through relay carrier. 442
|
