tion sender -G384- (up to 2006) Vehicle inclination sender -G384- (from 2007) ⇒ page 431 The vehicle inclination sender -G384- -arrow- is located on the right beneath the dash panel, behind the front passenger's airbag. Note The anti-theft alarm system must be deactivated before vehicle inclination sender -G384- is removed ⇒ page 430 . Caution ♦ Switch off ignition and all electrical consumers. Removing Rep. gr. 68 . – Unscrew bolts -1- and remove vehicle inclination sensor - G384- from bracket. – Detach connector -2- from vehicle level sender -G384- . 9.7 Vehicle inclination sender -G384- (from MY2010) Note ♦ The anti-theft alarm sensor -G578- includes the vehicle incli‐ nation sender -G384- and the interior monitoring sensor - G273- (two sensors). ♦ The anti-theft alarm sensor -G578- cannot be dismantled. Removing and installing anti-theft alarm sensor -G578- ⇒ page 432 . 434
|
