Volkswagen Golf Variant / Jetta. Manual - part 572





of this.

3. DSG Transmission Mechatronic J743

109

110

T10407- should rest completely on the transmission housing.

Caution

– Use some force at the top of the handle when turning.
This prevents the handle from sliding out when turning it.

3. DSG Transmission Mechatronic J743

111

wise. Then press the engaging lever away from the plungers

direction of the -arrow-.

Do not remove the Assembly Lever - Mechatronic - T10407- . It

must stay inserted between the engaging lever and the transmis‐

sion housing for the entire procedure.
– If necessary, push the Assembly Lever - Mechatronic -

T10407- against the transmission using a screwdriver.

112
