Volkswagen Golf / Golf Plus. Manual - part 277





s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

3

Radiator grille

3.1

Tools

Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1783-

3.2

Assembly overview - radiator grille

1 - Radiator grille

❑ Material: ASA

2 - Retaining hook

❑ Qty. 6

3 - VW emblem

❑ Clipped into radiator

grille

❑ Only remove when the

radiator grille is re‐

moved

❑ Removing: release lock‐

ing hooks on rear of VW

emblem with radiator

grille removed.

❑ Installing: guide VW em‐

blem with locking hooks

into recesses in radiator

grille -arrow b-, then turn

slightly in direction of

-arrow c- until VW em‐

blem engages in radia‐

tor grille.

4 - Bolt

❑ Qty. 2
❑ 2 Nm

General body repairs, exterior - Edition 04.2008

3. Radiator grille

229

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

3.3

Removing and installing radiator grille

3.3.1

Removing

– Remove bolts -4-.
– Release clips -arrows- on lock carrier using a small screw‐

driver.

– Tilt radiator grille -1- backwards slightly and pull locking hooks

-2- upwards out of bumper cover.

General body repairs, exterior - Edition 04.2008

230

     Rep. Gr.66 - Exterior equipment

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

3.3.2

Installing

– With radiator grille-1- tilted forward slightly place locking hooks

-2- in the bumper cover.

– Clip radiator -1- to lock carrier and engage clips -arrows- in

lock carrier.

– Install bolts -4-.

3.4

Assembly overview - radiator grille for

GTI, GTI special models and GT

Note

Minor differences will be encountered on removal and instal‐

ling, depending on version.

The radiator grilles for the Golf GT and the Golf GTI differ only

in their appearance.

The radiator grille for the Golf GTI has a honeycomb pattern,

the radiator grille for the Golf GT has transverse pieces.

General body repairs, exterior - Edition 04.2008

3. Radiator grille

231

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

1 - Radiator grille

❑ Different appearance

for Golf GT and Golf GTI

❑ Material: ASA

2 - Bolt

❑ Qty. 2
❑ 2 Nm

3 - Decorative trim

❑ Only for Golf GTI
❑ Engaged in radiator

grille

4 - Spreader rivet

❑ Qty. 4

5 - Number plate carrier

❑ For various countries
❑ Secured to radiator

grille with spreader clips

❑ For radiator grille with

no securing holes

⇒ page 235

6 - VW emblem

❑ Clipped into radiator

grille

❑ Only remove when the

radiator grille is re‐

moved

❑ Removing: release lock‐

ing hooks on rear of VW

emblem with radiator

grille removed.

❑ Installing: guide VW em‐

blem with locking hooks

into recesses in radiator grille -arrow b-, then turn slightly in direction of -arrow c- until VW emblem

engages in radiator grille.

7 - Front GTI lettering

❑ Engaged in radiator grille
❑ Only remove when the radiator grille is removed
❑ Unhook locking hooks from rear

8 - Bolt

❑ Qty. 2
❑ 2 Nm

9 - Retaining hook

❑ Qty. 2

10 - Guide hook

❑ Qty. 4

General body repairs, exterior - Edition 04.2008

232

     Rep. Gr.66 - Exterior equipment
