Additional work

Page

– Air filter element: Renew and clean housing

• Valid for Golf GTI “Edition 30” and Golf GTI “Pirelli”
• Rubber buffers for engine cover in conjunction with “Renewing air filter element”

⇒ page 95

⇒ page 80

– Sliding sunroof drains: Check flow and clean if necessary

• Only valid for North America

⇒ page 129

Every 90,000 km

Additional work

Page

– Air filter element: Renew and clean housing

• Not valid for Golf GTI “Edition 30” and Golf GTI “Pirelli”
• Applies to vehicles driving more than 90,000 km in 6 years

page 80

– Fuel filter: Renew

• When using diesel conforming to EN 590

page 74

– Spark plugs: Renew

• Applies to vehicles driving more than 90,000 km in 6 years
• Only valid for 1.8 TSI, 2.0 TSI; 2.0 TFSI and V6 FSI engine

page 146

At 90,000 km then every 30,000 km

Additional work

Page

– Camshaft drive toothed belt: Check

• Only valid for petrol engines without prescribed toothed belt change interval

⇒ page 145

Every 120,000 km

Additional work

Page

– Camshaft drive toothed belt: Renew

• Only valid for 4-cylinder TDI unit injector engines up to model year 2006
• It is not necessary to renew before the current interval

⇒ page 145

– Camshaft drive toothed belt: Renew

• Only valid for 4-cylinder SDI unit injector engines
• It is not necessary to renew before the current interval

⇒ page 145

Maintenance - Edition 11.2009

26

    2. Service work

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

Every 150,000 km

Additional work

Page

– Camshaft drive toothed belt: Renew

• Only valid for 4-cylinder TDI unit injector engines from model year 2007
• It is not necessary to renew before the current interval

⇒ page 145

At 150,000 km then every 30,000 km

– Diesel particulate filter: Check

• Vehicles with factory-fitted diesel particulate filter

⇒ page 1

⇒ page 60

Every 180,000 km

Additional work

Page

– Camshaft drive toothed belt: Renew

• Valid for 2.0 l FSI and 147 and 169 kW TFSI engines
• It is not necessary to renew before the current interval

⇒ page 145

Every 240,000 km

Additional work

Page

– Toothed belt tensioning roller: Renew

• Only valid for 4-cylinder TDI unit injector engines up to model year 2006
• It is not necessary to renew before the current interval

⇒ page 145

– Toothed belt tensioning roller: Renew

• Only valid for 4-cylinder SDI unit injector engines
• It is not necessary to renew before the current interval

⇒ page 145

Every 300,000 km

Additional work

Page

– Toothed belt tensioning roller: Renew

• Only valid for 4-cylinder TDI unit injector engines from model year 2007
• It is not necessary to renew before the current interval

⇒ page 145

Every 12 months (only valid for Germany)

Additional work

Page

– Exhaust emissions test: Perform test

• For vehicles with commercial passenger transport, e.g. taxis

⇒ page 160

Maintenance - Edition 11.2009

2. Service work

27

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

Every 2 years

Additional work

Page

– Brake and clutch system: Change brake fluid

• Only valid for vehicles ▸2007

⇒ page 53

– Renew dust and pollen filter (cabin filter)

• Only valid for vehicles driving less than 60,000 km in 2 years

⇒ page 118

3 years after initial registration and then every 2 years

– Brake and clutch system: Change brake fluid

• Only valid for vehicles 2008▸

page 53

– Exhaust emissions test (EET): Perform test

• For commercial passenger transport, e.g. taxis: every 12 months
• Only valid for Germany

page 160

Every 4 years

Additional work

Page

– Spark plugs: Renew

• Only valid for vehicles driving less than 60,000 km in 4 years
• Not valid for 1.8 TSI, 2.0 TSI; 2.0 TFSI and V6 FSI engine

page 146

Every 6 years

Additional work

Page

– Air filter: Clean housing and renew filter element

• Not valid for Golf GTI “Edition 30” and Golf GTI “Pirelli”
• Only valid for vehicles driving less than 90,000 km in 6 years

page 80

– Spark plugs: Renew

• Only valid for vehicles driving less than 90,000 km in 6 years
• Only valid for 1.8 TSI, 2.0 TSI; 2.0 TFSI and V6 FSI engine

page 146

Maintenance - Edition 11.2009

28

    2. Service work

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

3

General

In this chapter you will obtain information on the following sub‐

jects:
Raising vehicle with lifting platform and trolley jack

⇒ page 29

Sticker

⇒ page 30

Entries in service schedule

⇒ page 32

Connecting vehicle diagnostic tester

⇒ page 32

Vehicle identification number

⇒ page 34

Vehicle data sticker

⇒ page 36

Severe operating conditions

⇒ page 36

Engine code and engine number

⇒ page 37

RME fuel (biodiesel) for vehicles up to 05.2006

⇒ page 37

Type plate

⇒ page 38

3.1

Raising vehicle with lifting platform and

trolley jack

3.1.1

Safety notes:

WARNING

♦ Before driving onto a lifting platform, ensure that there is

sufficient clearance between low-lying vehicle compo‐

nents and lifting platform.

♦ Before driving a vehicle onto a lifting platform it must be

ensured that the vehicle weight does not exceed the per‐

missible lifting capacity of the platform.

♦ Vehicle may be lifted only at points indicated in figure to

avoid damaging vehicle floor pan or tipping vehicle.

♦ Never start engine and engage a gear with vehicle lifted

as long as even one driven wheel has contact with the

floor! Disregarding these warnings risks the danger of an

accident!

♦ If work is to be performed under vehicle, it must be sup‐

ported by suitable stands.

3.1.2

Lifting points for lifting platform and trol‐

ley jack:

Front lifting point:
– Position support plate, in area of side member marking

-arrow A-, at vertical reinforcement of floor pan -arrow B-.

WARNING

Ensure  that  side  member  reinforcement  seats  centrally  on

support plate of hoist mounting.

Maintenance - Edition 11.2009

3. General

29
