Toyota 4Runner (2022 year). Manual in english - page 12

6-3. Do-it-yourself maintenance

447

NOTICE

■Repairing or replacing tires, wheels, tire pressure warning valves,

transmitters and tire valve caps

●When removing or fitting the wheels, tires or the tire pressure warning

valves and transmitters, contact your Toyota dealer as the tire pres-

sure warning valves and transmitters may be damaged if not handled

correctly.

● Make sure to install the tire valve caps. If the tire valve caps are not

installed, water could enter the tire pressure warning valves and the

tire pressure warning valves could be bound.

●When replacing tire valve caps, do not use tire valve caps other than

those specified. The cap may become stuck.

■ To avoid damage to the tire pressure warning valves and transmit-

ters

When a tire is repaired with liquid sealants, the tire pressure warning

valve and transmitter may not operate properly. If a liquid sealant is

used, contact your Toyota dealer or other qualified service shop as soon

as possible. Make sure to replace the tire pressure warning valve and

transmitter when replacing the tire. (P. 438)

■Driving on rough roads

Take particular care when driving on roads with loose surfaces or pot-

6

holes.

These conditions may cause losses in tire inflation pressure, reducing

the cushioning ability of the tires. In addition, driving on rough roads

may cause damage to the tires themselves, as well as the vehicle’s

wheels and body.

■If tire inflation pressure of each tire becomes low while driving

Do not continue driving, or your tires and/or wheels may be ruined.

448

6-3. Do-it-yourself maintenance

Tire inflation pressure

Tire inflation pressure

The recommended cold tire

infla-

tion pressure and tire size are dis-

played on the tire and loading

information label. (P. 545)

6-3. Do-it-yourself maintenance

449

Inspection and adjustment procedure

1

Tire valve

2

Tire pressure gauge

1

Remove the tire valve cap.

2

Press the tip of the tire pressure gauge onto the tire valve.

3

Read the pressure using the gauge gradations.

4

If the tire inflation pressure is not at the recommended level, adjust

the pressure.

If you add too much air, press the center of the valve to deflate.

After completing the tire inflation pressure measurement and

5

adjustment, apply soapy water to the valve and check for leakage.

Put the tire valve cap back on.

6

6

■ Tire inflation pressure check interval

You should check tire inflation pressure every two weeks, or at least once

a month.

Do not forget to check the spare.

■Effects of incorrect tire inflation pressure

Driving with incorrect tire inflation pressure may result in the following:

●Reduced fuel economy

●Reduced driving comfort and poor handling

●Reduced tire life due to wear

●Reduced safety

●Damage to the drive train

If a tire needs frequent inflating, have it checked by your Toyota dealer.

6-3. Do-it-yourself maintenance

451

Wheels

If a wheel is bent, cracked or heavily corroded, it should be

replaced. Otherwise, the tire may separate from the wheel or

cause a loss of handling control.

Wheel selection

When replacing wheels, care should be taken to ensure that they are

equivalent to those removed in load capacity, diameter, rim width and

inset*.

Replacement wheels are available at your Toyota dealer.

: Conventionally referred to as “offset”.

Toyota does not recommend using the following:

● Wheels of different sizes or types

● Used wheels

● Bent wheels that have been straightened

Aluminum wheel precautions

● Use only Toyota wheel nuts and wrenches designed for use with

6

your aluminum wheels.

● When rotating, repairing or changing your tires, check that the

wheel nuts are still tight after driving 1000 miles (1600 km).

● Be careful not to damage the aluminum wheels when using tire

chains.

● Use only Toyota genuine balance weights or equivalent and a plas-

tic or rubber hammer when balancing your wheels.

452

6-3. Do-it-yourself maintenance

■When replacing wheels

The wheels of your vehicle are equipped with tire pressure warning

valves and transmitters that allow the tire pressure warning system to

provide advance warning in the event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pressure warning valves and trans-

mitters must be installed. (P. 438)

WARNING

■When replacing wheels

● Do not use wheels that are a different size from those recommended in

the Owner’s Manual, as this may result in a loss of handling control.

●Never use an inner tube in a leaking wheel which is designed for a

tubeless tire. Doing so may result in an accident, causing death or seri-

ous injury.

■When installing the wheel nuts

Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tightened, lead-

ing to bolt or disc wheel damage. In addition, the oil or grease can cause the

wheel nuts to loosen and the wheel may fall off, causing an accident and

resulting in death or serious injury. Remove any oil or grease from the wheel

bolts or wheel nuts.

NOTICE

■Replacing tire pressure warning valves and transmitters

●Because tire repair or replacement may affect the tire pressure warn-

ing valves and transmitters, make sure to have tires serviced by your

Toyota dealer or other qualified service shop. In addition, make sure to

purchase your tire pressure warning valves and transmitters at your

Toyota dealer.

●Ensure that only genuine Toyota wheels are used on your vehicle.

Tire pressure warning valves and transmitters may not work properly

with non-genuine wheels.

6-3. Do-it-yourself maintenance

453

Air conditioning filter

The air conditioning filter must be changed regularly to maintain

air conditioning efficiency.

Removal method

1

Turn the engine switch off.

2

Open the glove box and

remove the cover.

3

Remove the filter cover.

6

4

Remove the air conditioning fil-

ter and replace it with a new

one.

The “UP” marks shown on the fil-

ter should be pointing up.

6-3. Do-it-yourself maintenance

455

Wireless remote control/electronic key

battery

Replace the battery with a new one if it is depleted.

You will need the following items:

● Flathead screwdriver

● Small flathead screwdriver

● Lithium battery CR2016 (vehicles without a smart key system), or

CR2032 (vehicles with a smart key system)

Replacing the battery (vehicles without a smart key system)

1

Remove the cover.

To prevent damage to the key,

cover the tip of the screwdriver with

a rag.

6

Remove the module.

2

Open the case cover using a

3

coin protected with tape etc.

and remove the depleted bat-

tery.

Insert a new battery with the “+”

terminal facing up.

456

6-3. Do-it-yourself maintenance

Replacing the battery (vehicles with a smart key system)

Release the lock and remove

1

the mechanical key.

Remove the key cover.

2

To prevent damage to the key,

cover the tip of the flathead screw-

driver with a rag.

Remove the depleted battery

3

using a small flathead screw-

driver.

When removing the cover, the

electronic key module may stick to

the cover and the battery may not

be visible. In this case, remove the

electronic key module in order to

remove the battery.

Insert a new battery with the “+” terminal facing up.

4

When installing the key cover and mechanical key, install by con-

ducting

2

and

1

with the directions reversed.

5

Operate the

or

switch and check that the doors can

be locked/unlocked.

6-3. Do-it-yourself maintenance

457

■ When replacing the key battery

Be careful not to lose the battery or any other small parts.

■ Use a CR2016 (vehicles without a smart key system) or CR2032 (vehicles

with a smart key system) lithium battery

● Batteries can be purchased at your Toyota dealer, local electrical appliance

shops or camera stores.

● Replace only with the same or equivalent type recommended by the manu-

facturer.

● Dispose of used batteries according to local laws.

■ If the electronic key battery is depleted

The following symptoms may occur:

● The smart key system and wireless remote control will not function properly.

● The operational range will be reduced.

WARNING

■ Battery precautions

Observe the following precautions.

Failure to do so may result in death or serious injury.

● Do not swallow the battery. Doing so may cause chemical burns.

● A coin battery or button battery is used in the wireless remote control/elec-

tronic key. If a battery is swallowed, it may cause severe chemical burns in

6

as little as 2 hours and may result in death or serious injury.

● Keep away new and removed batteries from children.

● If the cover cannot be firmly closed, stop using the wireless remote con-

trol/electronic key and stow the key in the place where children cannot

reach, and then contact your Toyota dealer.

● If you accidentally swallow a battery or put a battery into a part of your

body, get emergency medical attention immediately.

■ To prevent battery explosion or leakage of flammable liquid or gas

● Replace the battery with a new battery of the same type. If a wrong type of

battery is used, it may explode.

● Do not expose batteries to extremely low pressure due to high altitude or

extremely high temperatures.

● Do not burn, break or cut a battery.

458

6-3. Do-it-yourself maintenance

NOTICE

■For normal operation after replacing the battery

Observe the following precautions to prevent accidents:

● Always work with dry hands.

Moisture may cause the battery to rust.

● Do not touch or move any other component inside the remote control.

● Do not bend either of the battery terminals.

6-3. Do-it-yourself maintenance

459

Checking and replacing fuses

If any of the electrical components do not operate, a fuse may

have blown. If this happens, check and replace the fuses as nec-

essary.

1

Turn the engine switch off.

2

Open the Fuse box cover.

 Engine compartment

Push the tab in and lift the lid off.

 Driver’s side instrument panel

Remove the lid.

6

3

Remove the fuse with the pull-

out tool.

Only type A fuse can be removed

using the pullout tool.

460

6-3. Do-it-yourself maintenance

4

Check if the fuse is blown.

1

Normal fuse

2

Blown fuse

Type A, B, C, D, E:

Replace the blown fuse with a new fuse of an appropriate amperage rat-

ing. The amperage rating can be found on the fuse box lid.

Type F:

Contact your Toyota dealer.

 Type A

 Type B

 Type C

 Type D

 Type E

 Type F

6-3. Do-it-yourself maintenance

461

■ After a fuse is replaced

● If the lights do not turn on even after the fuse has been replaced, a bulb may

need replacement. (P. 462)

● If the replaced fuse blows again, have the vehicle inspected by your Toyota

dealer.

■ If there is an overload in a circuit

The fuses are designed to blow, protecting the wiring harness from damage.

WARNING

■ To prevent system breakdowns and vehicle fire

Observe the following precautions.

Failure to do so may cause damage to the vehicle, and possibly a fire or

injury.

● Never use a fuse of a higher amperage rating than that indicated, or use

any other object in place of a fuse.

● Always use a genuine Toyota fuse or equivalent.

Never replace a fuse with a wire, even as a temporary fix.

● Do not modify the fuses or fuse boxes.

NOTICE

6

■ Before replacing fuses

Have the cause of electrical overload determined and repaired by your

Toyota dealer as soon as possible.

462

6-3. Do-it-yourself maintenance

Light bulbs

You may replace the following bulbs by yourself. The difficulty

level of replacement varies depending on the bulb. If necessary

bulb replacement seems difficult to perform, contact your

Toyota dealer.

For more information about replacing other light bulbs, contact

your Toyota dealer.

Preparing for light bulb replacement

Check the wattage of the light bulb to be replaced. (P. 541)

6-3. Do-it-yourself maintenance

463

Bulb locations

■ Front

1

Headlight high beam

(if

3

Front side marker light

equipped)/daytime running

light

2

Front turn signal/parking

light

6

■ Rear

1

Rear turn signal light

2

Back-up light

3

License plate light

464

6-3. Do-it-yourself maintenance

Replacing light bulbs

■ Headlight high beam (if equipped)/daytime running lights

1

Turn the bulb base counter-

clockwise.

Pull the bulb out while press-

2

ing the lock release of the

connector.

Replace the light bulb, and

3

install the bulb base.

Align the 3 tabs on the light bulb

with the mounting and insert.

4

Turn and secure the bulb

base.

Shake the bulb base gently to

check that it is not loose, turn

the headlights on once and visu-

ally confirm that no light is leak-

ing through the mounting.

6-3. Do-it-yourself maintenance

465

■ Front turn signal/parking light

Turn the steering wheel in

1

the opposite direction of the

front turn signal light and

parking light that you wish to

replace.

For example, if you wish to

replace the front turn signal light

and parking light on the right

side, turn the steering wheel to

the left.

2

Remove the fender liner

screws.

3

Partly remove the fender

liner.

6

466

6-3. Do-it-yourself maintenance

4

Turn the bulb base counter-

clockwise.

5

Remove the light bulb.

6

When installing, reverse the steps listed.

6-3. Do-it-yourself maintenance

467

■ Front side marker lights

Turn the steering wheel in

1

the opposite direction of the

front side marker light that

you wish to replace.

For example, if you wish to

replace the front side marker

light on the right side, turn the

steering wheel to the left.

2

Remove the fender liner

screws.

3

Partly remove the fender

liner.

6

468

6-3. Do-it-yourself maintenance

4

Turn the bulb base counter-

clockwise.

5

Remove the light bulb.

6

When installing, reverse the steps listed.

6-3. Do-it-yourself maintenance

469

■ Rear turn signal lights

Open the back door and

1

remove the cover.

To prevent damage to the vehi-

cle, cover the tip of the screw-

driver with a rag.

2

Turn the bulb base counter-

clockwise.

3

Remove the light bulb.

6

When installing, reverse the steps listed.

4

470

6-3. Do-it-yourself maintenance

■ Back-up lights

Open the back door and

1

remove the cover.

To prevent damage to the vehi-

cle, cover the tip of the screw-

driver with a rag.

2

Turn the bulb base counter-

clockwise.

3

Remove the light bulb.

4

When installing, reverse the steps listed.

6-3. Do-it-yourself maintenance

471

■ License plate lights

1

Remove the screws and

lens.

2

Remove the light bulb.

6

3

When installing, reverse the steps listed.

472

6-3. Do-it-yourself maintenance

■ Replacing the following bulbs

If any of the lights listed below has burnt out, have it replaced by

your Toyota dealer.

● Headlight low beams (if equipped)

● Headlight low/high beams (if equipped)

● Fog lights

● Side turn signal lights

● Stop/tail lights

● Rear side marker lights

● High mounted stoplight

● Outer foot lights (if equipped)

■ LED light bulbs

The headlight low beams

(if equipped), headlight low/high beams

(if

equipped), fog lights, side turn signal lights, stop/tail lights, rear side marker

lights, high mounted stoplight and outer foot lights consist of a number of

LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have

the light replaced.

■Condensation build-up on the inside of the lens

Temporary condensation build-up on the inside of the lens does not indicate a

malfunction. Contact your Toyota dealer for more information in the following

situations:

● Large drops of water have built up on the inside of the lens.

● Water has built up inside the lens.

WARNING

■Replacing light bulbs

● Turn off the lights. Do not attempt to replace the bulb immediately after

turning off the lights.

The bulbs become very hot and may cause burns.

● Do not touch the glass portion of the light bulb with bare hands. When it is

unavoidable to hold the glass portion, use and hold with a clean dry cloth

to avoid getting moisture and oils on the bulb.

Also, if the bulb is scratched or dropped, it may blow out or crack.

● Fully install light bulbs and any parts used to secure them. Failure to do so

may result in heat damage, fire, or water entering the headlight unit. This

may damage the headlights or cause condensation to build up on the lens.

■ To prevent damage or fire

● Make sure bulbs are fully seated and locked.

● Check the wattage of the bulb before installing to prevent heat damage.

474

7-1. Essential information

Emergency flashers

The emergency flashers are used to warn other drivers when the

vehicle has to be stopped in the road due to a breakdown, etc.

Press the switch.

All the turn signals will flash.

To turn them off, press the switch

once again.

■ Emergency flashers

If the emergency flashers are used for a long time while the engine is not

operating, the battery may discharge.

7-1. Essential information

475

If your vehicle has to be stopped in an

emergency

Only in an emergency, such as if it becomes impossible to stop

the vehicle in the normal way, stop the vehicle using the follow-

ing procedure:

1

Steadily step on the brake pedal with both feet and firmly depress it.

Do not pump the brake pedal repeatedly as this will increase the effort

required to slow the vehicle.

2

Shift the shift lever to N.

 If the shift lever is shifted to N

3

After slowing down, stop the vehicle in a safe place by the road.

4

Stop the engine.

 If the shift lever cannot be shifted to N

3

Keep depressing the brake pedal with both feet to reduce vehicle

speed as much as possible.

Vehicles without a smart key

4

system: Stop the engine by

turning the engine switch to the

“ACC” position.

7

Vehicles with a smart key sys-

4

tem: To stop the engine, press

and hold the engine switch for 2

consecutive seconds or more,

or press it briefly

3 times or

more in succession.

Press and hold for 2 seconds or more

or press briefly 3 times or more

Stop the vehicle in a safe place by the road.

5

7-1. Essential information

477

If the vehicle is submerged or water on the

road is rising

This vehicle is not designed to be able to drive on roads that are

deeply flooded with water. Do not drive on roads where the

roads may be submerged or the water may be rising. It is dan-

gerous to remain in the vehicle, if it anticipated that the vehicle

will be flooded or set a drift. Remain calm and follow the follow-

ing.

● If the door can be opened, open the door and exit the vehicle.

● If the door can not be opened, open the window using the power

window switch and ensure an escape route.

● If the window can be opened, exit the vehicle through the window.

● If the door and window cannot be opened due to the rising water,

remain calm, wait until the water level inside the vehicle rises to the

point that the water pressure inside of the vehicle equals the water

pressure outside of the vehicle and then open the door after waiting

for the rising water to enter the vehicle, and exit the vehicle. When

the outside water level exceeds half the height of the door, the door

cannot be opened from the inside due to water pressure.

7

■ Water level exceeds the floor

When the water level exceeds the floor and time has passed, the electrical

equipment will get damaged, the power windows will not operate, the engine

stop, and the vehicle may not be able to get moving.

■ Using an emergency escape hammer*

Laminated glass is used in the windshield on this vehicle. Laminated glass

cannot be shattered with an emergency hammer*.

Tempered glass is used in the windows on this vehicle.

*: Contact your Toyota dealer or aftermarket accessory manufacturer for fur-

ther information about an emergency hammer.

WARNING

■Caution while driving

Do not drive on roads where the roads may be submerged or the water may

be rising. Otherwise the vehicle may be damaged and cannot move, as well

as become flooded and set a drift, which may lead to death.

478

7-2. Steps to take in an emergency

If your vehicle needs to be towed

If towing is necessary, we recommend having your vehicle

towed by your Toyota dealer or commercial towing service,

using a wheel-lift type truck or flatbed truck.

Use a safety chain system for all towing, and abide by all state/

provincial and local laws.

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■ When towing the vehicle

2WD models: Be sure to transport the

vehicle with the rear wheels raised or

with all four wheels raised off the ground.

If the vehicle is towed with the rear

wheels contacting the ground, the drive-

train and related parts may be damaged

or an accident may occur due to a

change in direction of the vehicle.

4WD models: Be sure to transport the

vehicle with all four wheels raised off the

ground. If the vehicle is towed with the

tires contacting the ground, the drivetrain

or related parts may be damaged, the

vehicle may fly off the truck.

7-2. Steps to take in an emergency

479

WARNING

■ While towing

● When towing using cables or chains, avoid sudden starts, etc. which place

excessive stress on the towing eyelets, cables or chains. The towing eye-

lets, cables or chains may become damaged, broken debris may hit peo-

ple, and cause serious damage.

● Vehicles with a smart key system: Do not turn the engine switch off.

There is a possibility that the steering wheel is locked and cannot be oper-

ated.

● Vehicles without a smart key system: Do not turn the engine switch to the

“LOCK” position.

There is a possibility that the steering wheel is locked and cannot be oper-

ated.

NOTICE

■ To prevent damage to the vehicle when towing using a wheel-lift type

truck

● Vehicles with a smart key system: Do not tow the vehicle from the rear

when the engine switch is off. The steering lock mechanism is not strong

enough to hold the front wheels straight.

● Vehicles without a smart key system: Do not tow the vehicle from the rear

when the engine switch is in the “LOCK” position or the key is removed.

The steering lock mechanism is not strong enough to hold the front wheels

straight.

7

● When raising the vehicle, ensure adequate ground clearance for towing at

the opposite end of the raised vehicle. Without adequate clearance, the

vehicle could be damaged while being towed.

■ To prevent damage to the vehicle when towing with a sling-type truck

Do not tow with a sling-type truck, either from the front or rear.

■ To prevent damage to the vehicle during emergency towing

Do not secure cables or chains to the suspension components.

■ Recreational towing (behind motor home, etc.) (4WD models)

Never dinghy tow your vehicle to prevent

causing serious damage to the transmis-

sion. (P. 206)

480

7-2. Steps to take in an emergency

Situations when it is necessary to contact dealers before towing

The following may indicate a problem with your transmission. Contact

your Toyota dealer or commercial towing service before towing.

● The engine is running but the vehicle does not move.

● The vehicle makes an abnormal sound.

Towing with a wheel-lift type truck

 From the front

Use a towing dolly under the rear

wheels.

 From the rear (2WD models)

Turn the engine switch to the

“ACC” position (vehicles without a

smart key system) or ACCES-

SORY mode

(vehicles with a

smart key system) so that the

steering wheel is unlocked.

 From the rear (4WD models)

Use a towing dolly under the front

wheels.

7-2. Steps to take in an emergency

481

NOTICE

■ Towing with a sling-type truck

Do not tow with a sling-type truck to pre-

vent body damage.

Using a flatbed truck

When using a flat-bed truck to transport the vehicle, use tire strapping

belts. Refer to the owner's manual of the flat-bed truck for the tire

strapping method.

Vehicles with a smart key system: In order to suppress vehicle move-

ment during transportation, set the parking brake and turn the engine

switch off.

Vehicles without a smart key system: In order to suppress vehicle

movement during transportation, set the parking brake and turn the

engine switch to the “LOCK” position.

Emergency towing

7

If a tow truck is not available in an emergency, your vehicle may be

temporarily towed using cables or chains secured to the emergency

towing hooks. This should only be attempted on hard surfaced roads

for at most 80 km (50 miles) at under 30 km/h (18 mph).

A driver must be in the vehicle to steer and operate the brakes. The

vehicle’s wheels, drive train, axles, steering and brakes must be in

good condition.

482

7-2. Steps to take in an emergency

Emergency towing procedure

1

Vehicles with front covers only:

Before using the front emer-

gency towing eyelet(s), remove

the cover(s).

1

Removing the clips

2

Installing the clips

Securely attach cables or

2

chains to the towing hook.

Take care not to damage the vehi-

cle body.

Enter the vehicle being towed and start the engine.

3

Vehicles with a smart key system: If the engine does not start, turn the

engine switch to ON.

Vehicles without a smart key system: If the engine does not start, turn the

engine switch to the “ON” position.

7-2. Steps to take in an emergency

483

4

Part-time 4WD models:

 Type A

Shift the front-wheel drive control lever to H2.

 Type B

Push the “UNLOCK” button and turn the front-wheel drive control

switch to H2.

Full-time 4WD models: Push the “UNLOCK” button and turn the

four-wheel drive control switch to H4F. (The center differential is

unlocked.)

Shift the shift lever to N and release the parking brake.

5

When the shift lever cannot be shifted: P. 219

■ While towing

If the engine is not running, the power assist for the brakes and steering will

not function, making steering and braking more difficult.

7

484

7-2. Steps to take in an emergency

If you think something is wrong

If you notice any of the following symptoms, your vehicle proba-

bly needs adjustment or repair. Contact your Toyota dealer as

soon as possible.

Visible symptoms

● Fluid leaks under the vehicle.

(Water dripping from the air conditioning after use is normal.)

● Flat-looking tires or uneven tire wear

● Engine coolant temperature gauge needle continually points higher

than normal.

Audible symptoms

● Changes in exhaust sound

● Excessive tire squeal when cornering

● Strange noises related to the suspension system

● Pinging or other noises related to the engine

Operational symptoms

● Engine missing, stumbling or running roughly

● Appreciable loss of power

● Vehicle pulls heavily to one side when braking

● Vehicle pulls heavily to one side when driving on a level road

● Loss of brake effectiveness, spongy feeling, pedal almost touches

the floor

7-2. Steps to take in an emergency

485

Fuel pump shut off system

To minimize the risk of fuel leakage when the engine stalls or

when an airbag inflates upon collision, the fuel pump shut off

system stops the supply of fuel to the engine.

Follow the procedure below to restart the engine after the system is

activated.

 Vehicles without a smart key system

1

Turn the engine switch to the “ACC” or “LOCK” position.

2

Restart the engine.

 Vehicles with a smart key system

1

Turn the engine switch to ACCESSORY mode or turn it off.

2

Restart the engine.

NOTICE

■Before starting the engine

Inspect the ground under the vehicle.

If you find that fuel has leaked onto the ground, the fuel system has been

damaged and is in need of repair. Do not restart the engine.

7

486

7-2. Steps to take in an emergency

If a warning light turns on or a warning

buzzer sounds

Calmly perform the following actions if any of the warning lights

comes on or flashes. If a light comes on or flashes, but then

goes off, this does not necessarily indicate a malfunction in the

system. However, if this continues to occur, have the vehicle

inspected by your Toyota dealer.

Warning light and warning buzzer list

Warning light

Warning light/Details/Actions

Brake system warning light (warning buzzer)

• Low brake fluid

• Malfunction in the brake system

This light also comes on when the parking brake is not

(U.S.A.)

released. If the light turns off after the parking brake is

fully released the system is operating normally.

 Immediately stop the vehicle in a safe place and

(Canada)

contact your Toyota dealer. Continuing to drive

the vehicle may be dangerous.

High coolant temperature warning light

(warning

buzzer)*⁴

Indicates that the engine coolant temperature is too

high

 Immediately stop the vehicle in a safe place.

Handling method (P. 527)

Charging system warning light

Indicates a malfunction in the vehicle’s charging sys-

tem

 Immediately stop the vehicle in a safe place and

contact your Toyota dealer.

Low engine oil pressure warning light*⁴

Indicates that the engine oil pressure is too low

 Immediately stop the vehicle in a safe place and

contact your Toyota dealer.

Content      ..     10      11      12      13     ..
