Toyota Yaris Hybrid (2017 year). Manual - part 17

272

5-4. Playing audio CDs and MP3/WMA discs

■ Switching the display

Press

Track title, Artist name and Album title (MP3 only) are shown on the dis-

play.

To return to the previous display, press

or

■ Display

Up to 24 characters can be displayed.

Depending on the contents recorded, the characters may not be displayed

properly or may not be displayed at all.

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to any

authorized Toyota dealer or repairer, or another duly qualified and equipped

professional.

Message

Cause

Correction procedures

• The disc is dirty or

• Clean the disc.

damaged.

“CD CHECK”

• Insert the disc cor-

• The disc is inserted

rectly.

upside down.

There is a malfunction

“ERROR”

Eject the disc.

within the system.

Wait for a while and

then press

Contact any autho-

Operation has stopped

rized Toyota dealer or

“WAIT”

due to a high tempera-

repairer, or another

ture inside the player.

duly

qualified

and

equipped professional

if the CD still cannot be

played.

MP3/WMA files are not

“NO SUPPORT”

Eject the disc.

included on the CD.

YARIS_HV_OM_Europe_OM52G76E

5-4. Playing audio CDs and MP3/WMA discs

273

■ Discs that can be used

Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or disc fea-

tures, or due to scratches, dirt or deterioration.

CDs with copy-protect features may not be used.

■ CD player protection feature

To protect the internal components, playback is automatically stopped when a

problem is detected while the CD player is being used.

■ If a disc is left inside the CD player or in the ejected position for

extended periods

The disc may be damaged and may not play properly.

■ Lens cleaners

Do not use lens cleaners. Doing so may damage the CD player.

■ MP3 and WMA files

MP3 (MPEG Audio LAYER3) is a Microsoft audio compression format.

Files can be compressed to approximately 1/10 of their original size by using

5

MP3 compression.

WMA (Windows Media Audio) is a Microsoft audio compression format.

This format compresses audio data to a size smaller than that of the MP3 for-

mat.

There is a limit to the MP3 and WMA file standards and to the media/formats

recorded by them that can be used.

●MP3 file compatibility

• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz)

MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps)

MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and mon-

aural

YARIS_HV_OM_Europe_OM52G76E

5-4. Playing audio CDs and MP3/WMA discs

275

●MP3 and WMA playback

When a disc containing MP3 or WMA files is inserted, all files on the disc

are first checked. Once the file check is finished, the first MP3 or WMA file

is played. To make the file check finish more quickly, we recommend you do

not write in any files other than MP3 or WMA files or create any unneces-

sary folders.

If the discs contain a mixture of music data and MP3 or WMA format data,

only music data can be played.

●Extensions

If the file extensions .mp3 and .wma are used for files other than MP3 and

WMA files, they will be mistakenly recognized and played as MP3 and

WMA files. This may result in large amounts of interference and damage to

the speakers.

●Playback

• To play MP3 files with steady sound quality, we recommend a fixed bit

rate of 128 kbps and a sampling frequency of 44.1 kHz.

• CD-R or CD-RW playback may not be possible in some instances,

depending on the characteristics of the disc.

• There is a wide variety of freeware and other encoding software for MP3

and WMA files on the market, and depending on the status of the encod-

5

ing and the file format, poor sound quality or noise at the start of playback

may result. In some cases, playback may not be possible at all.

• When files other than MP3 or WMA files are recorded on a disc, it may

take more time to recognize the disc and in some cases, playback may

not be possible at all.

• Microsoft, Windows, and Windows Media are the registered trademarks

of Microsoft Corporation in the U.S. and other countries.

WARNING

■ Certification for the CD player

This product is a class I laser product.

●Do not open the cover of the player or attempt to repair the unit yourself.

Refer servicing to qualified personnel.

● Laser power: No hazardous

YARIS_HV_OM_Europe_OM52G76E

276

5-4. Playing audio CDs and MP3/WMA discs

NOTICE

■ Discs and adapters that cannot be used

Do not use the following types of discs.

Also, do not use 8 cm (3 in.) disc adapters, Dual Discs or printable discs.

Doing so may damage the player and/or the disc insert/eject function.

●Discs that have a diameter that is not 12 cm (4.7 in.).

● Low-quality or deformed discs.

●Discs with a transparent or translucent recording area.

●Discs that have had tape, stickers or CD-R labels attached to them, or that

have had the label peeled off.

■ Player precautions

Failure to follow the precautions below may result in serious damage to the

discs or the player itself.

●Do not insert anything other than discs into the disc slot.

●Do not apply oil to the player.

● Store discs away from direct sunlight.

●Never try to disassemble any part of the player.

YARIS_HV_OM_Europe_OM52G76E

5-5. Using an external device

277

Listening to an iPod

Connecting an iPod enables you to enjoy music from the vehicle

speakers. Press

until “iPod” is displayed.

Connecting an iPod

P. 261

Control panel

5

1

Power

6

Selecting an iPod menu/song

2

Volume

or displays text message

7

Back button

3

iPod menu mode

8

Playback

4

Repeat play

9

Displays songs list

5

Shuffle playback

10

Selecting a song, fast-forward-

ing or reversing

: If equipped

YARIS_HV_OM_Europe_OM52G76E

278

5-5. Using an external device

Selecting a play mode

1

Press

(MENU) to select iPod menu mode.

2

Turning

clockwise changes the play mode in the following

order:

“Playlists”  “Artists” “Albums” “Songs” “Podcasts” 

“Genres” “Composers” “Audiobooks”

3

Press

to select the desired play mode.

■ Play mode list

First

Second

Third

Fourth

Play mode

selection

selection

selection

section

Playlists

“Playlists”

Songs select

-

-

select

“Artists”

Artists select

Albums select

Songs select

-

Albums

“Albums”

Songs select

-

-

select

“Songs”

Songs select

-

-

-

Podcasts

Episodes

“Podcasts”

-

-

select

select

“Genres”

Genre select

Artists select

Albums select

Songs select

Composers

“Composers”

Albums select

Songs select

-

select

Audiobooks

“Audiobooks”

-

-

-

select

YARIS_HV_OM_Europe_OM52G76E

5-5. Using an external device

279

■ Selecting a list

1

Turn

to display the first selection list.

2

Press

to select the desired item.

Pressing the knob changes to the second selection list.

Repeat the same procedure to select the desired item.

3

To return to the previous selection list, press

Selecting songs

Turn

or press “” or “” on

to select the desired song.

Selecting a song from the song list

1

Press

The song list will be displayed.

5

2

Turn

to select a song.

3

Press

to play the song.

To return to the previous display, press

Fast-forwarding and reversing songs

To fast-forward or reverse, press and hold “” or “” on

Repeat play

Press

(RPT).

To cancel, press

(RPT) again.

YARIS_HV_OM_Europe_OM52G76E

280

5-5. Using an external device

Shuffle playback

Pressing

(RDM) changes modes in the following order:

Track shuffle  Album shuffle  Off.

Switching the display

Press

Track title, Artist name and Album title are shown on the display.

To return to the previous display, press

or

Adjusting sound quality and volume balance

1

Press

to enter iPod menu mode.

2

Turning

changes sound modes. (P. 262)

■ About iPod

● “Made for iPod” and “Made for iPhone” mean that an electronic accessory

has been designed to connect specifically to iPod, or iPhone, respectively,

and has been certified by the developer to meet Apple performance stan-

dards.

●Apple is not responsible for the operation of this device or its compliance

with safety and regulatory standards. Please note and that the use of this

accessory with iPod or iPhone may affect wireless performance.

● iPod is trademark of Apple Inc., registered in the U.S. and other countries.

YARIS_HV_OM_Europe_OM52G76E

5-5. Using an external device

281

■ iPod functions

● When an iPod is connected and the audio source is changed to iPod mode,

the iPod will resume play from the same point in which it was last used.

●Depending on the iPod that is connected to the system, certain functions

may not be available. If a function is unavailable due to a malfunction (as

opposed to a system specification), disconnecting the device and recon-

necting it once again may resolve the problem.

● While connected to the system, the iPod cannot be operated with its own

controls. It is necessary to use the controls of the vehicle’s audio system

instead.

● When the battery level of an iPod is very low, the iPod may not operate. If

so, charge the iPod before use.

●Supported models (P. 282)

■ iPod problems

To resolve most problems encountered when using your iPod, disconnect

your iPod from the vehicle iPod connection and reset it.

For instructions on how to reset your iPod, refer to your iPod Owner’s Man-

ual.

■ Display

P. 272

5

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to any

authorized Toyota dealer or repairer, or another duly qualified and equipped

professional.

Message

Cause/Correction procedures

This indicates a problem in the iPod or its

“ERROR”

connection.

This indicates that there is no music data in

“NO SONGS”

the iPod.

This indicates that some available songs are

“NO PLAYLIST”

not found in a selected playlist.

This indicates that the version of the iPod is

“UPDATE YOUR IPOD”

not compatible. Upgrade your iPod software

to the latest version.

YARIS_HV_OM_Europe_OM52G76E

282

5-5. Using an external device

■ Compatible models

Model

Generation

Software version

iPod

5th generation

Ver. 1.3.0 or higher

1st generation

Ver. 1.3.1 or higher

2nd generation

Ver. 1.1.3 or higher

iPod nano

3rd generation

Ver. 1.1.3 or higher

4th generation

Ver. 1.0.4 or higher

5th generation

Ver. 1.0.1 or higher

1st generation

Ver. 3.1.2 or higher

2nd generation

Ver. 3.1.2 or higher

iPod touch

Late 2009 (8 GB)

Ver. 3.1.2 or higher

Late 2009 (32 GB/64 GB)

Ver. 3.1.2 or higher

1st generation

Ver. 1.1.2 or higher

iPod classic

2nd generation (120 GB)

Ver. 2.0.1 or higher

Late 2009 (160 GB)

Ver. 2.0.3 or higher

1st generation (iPhone)

Ver. 3.1.2 or higher

2nd generation (iPhone 3G)

Ver. 3.1.2 or higher

iPhone

3rd generation (iPhone 3GS)

Ver. 3.1.2 or higher

4th generation (iPhone 4)

Ver. 4.0.0 or higher

Depending on differences between models or software version etc., some

models listed above might be incompatible with this system.

iPod 4th generation and earlier models are not compatible with this system.

iPod mini, iPod shuffle and iPod photo are not compatible with this system.

Items related to standards and limitations are as follows:

●Maximum number of lists in device: 9999

● Maximum number of songs in device: 65535

● Maximum number of songs per list: 65535

YARIS_HV_OM_Europe_OM52G76E

5-5. Using an external device

283

WARNING

■ Caution while driving

Do not connect iPod or operate the controls.

NOTICE

■ To prevent damage to iPod

●Do not leave iPod in the vehicle. The temperature inside the vehicle may

become high, resulting in damage to the iPod.

●Do not push down on or apply unnecessary pressure to the iPod while it is

connected as this may damage the iPod or its terminal.

●Do not insert foreign objects into the port as this may damage the iPod or

its terminal.

5

YARIS_HV_OM_Europe_OM52G76E

284

5-5. Using an external device

Listening to a USB memory device

Connecting a USB memory device enables you to enjoy music

from the vehicle speakers. Press

until “USB” is dis-

played.

Connecting a USB memory

P. 261

Control panel

1

Power

6

Selecting a folder

2

Volume

7

Back button

3

Repeat play

8

Playback

4

Random playback

9

Displays folder list

5

Selecting a file or displays text

10

Selecting a file, fast-forward-

message

ing or reversing

: If equipped

YARIS_HV_OM_Europe_OM52G76E

5-5. Using an external device

285

Selecting a folder

■ Selecting a folders one at a time

Press “” or “” on

to select the desired folder.

■ Selecting a folder and file from folder list

1

Press

The folder list will be displayed.

2

Turn and press

to select a folder and a file.

To return to the previous display, press

To exit, press

■ Returning to the first folder

Press and hold “” on

until you hear a beep.

Selecting files

5

Turn

or press “” or “” on

to select the desired file.

Fast-forwarding and reversing files

To fast-forward or reverse, press and hold “” or “” on

Repeat play

Pressing

(RPT) changes modes in the following order:

File repeat  Folder repeat*  Off.

*: Available except when RDM (random playback) is selected

YARIS_HV_OM_Europe_OM52G76E

286

5-5. Using an external device

Random playback

Pressing

(RDM) changes modes in the following order:

Folder random  Disc random  Off.

Switching the display

Press

Track title, Artist name and Album title (MP3 only) are displayed on the dis-

play.

To return to the previous display, press

or

■ USB memory functions

● Depending on the USB memory that is connected to the system, the device

itself may not be operable and certain functions may not be available. If the

device is inoperable or a function is unavailable due to a malfunction (as

opposed to a system specification), disconnecting the device and recon-

necting it once again may resolve the problem.

● If the USB memory still does not begin operation after being disconnected

and reconnected, format the memory.

■ Display

P. 272

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to any

authorized Toyota dealer or repairer, or another duly qualified and equipped

professional.

Message

Cause/Correction procedures

This indicates a problem in the USB memory

“ERROR”

or its connection.

This indicates that no MP3/WMA files are

“NO MUSIC”

included in the USB memory device.

YARIS_HV_OM_Europe_OM52G76E

Content   ..  15  16  17  18   ..
