4-7. Driving tips
255
■ Tire chain installation
Observe the following precautions when installing and removing chains:
●Install and remove tire chains in a safe location.
● Install tire chains on the front tires only. Do not install tire chains on the rear
tires.
●Install tire chains on front tires as tightly as possible. Retighten chains after
driving 0.5 1.0 km (1/4 1/2 mile).
●Install tire chains following the instructions provided with the tire chains.
● If wheel ornaments are used, they will be scratched by the chain band, so
remove the ornaments before putting on the chains. (P. 420)
WARNING
■ Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
4
serious injury.
●Use tires of the specified size.
● Maintain the recommended level of air pressure.
●Do not drive at speeds in excess of the speed limit or the speed limit spec-
ified for the snow tires being used.
●Use snow tires on all, not just some wheels.
●Do not use tires of noticeably different wear level.
■ Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.
●Do not drive in excess of the speed limit specified for the tire chains being
used, or 50 km/h (30 mph), whichever is lower.
● Avoid driving on bumpy road surfaces or over potholes.
● Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.
●Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.
●Do not use LDA (Lane Departure Alert) (if equipped).
YARIS_HV_OM_Europe_OM52G76E
256
4-7. Driving tips
YARIS_HV_OM_Europe_OM52G76E
257
Audio system
5
5-1. Basic Operations
Audio system types
258
Steering wheel audio
switches
260
USB port
261
5-2. Using the audio system
Optimal use of the audio
system
262
5-3. Using the radio
Radio operation
264
5-4. Playing audio CDs and
MP3/WMA discs
CD player operation
269
5-5. Using an external device
Listening to an iPod
277
Listening to a USB
memory device
284
YARIS_HV_OM_Europe_OM52G76E
258
5-1. Basic Operations
Audio system types
Vehicles with a Navigation/Multimedia system
Owners of models equipped with a Navigation/Multimedia system
should refer to the “Navigation and multimedia system Owner’s Man-
ual”.
: If equipped
YARIS_HV_OM_Europe_OM52G76E
5-1. Basic Operations
259
Vehicles without a Navigation/Multimedia system
CD player and AM/FM radio
The illustration below is for left-hand drive vehicles. Some button posi-
tions are reversed for right-hand drive vehicles.
■ Using cellular phones
5
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
NOTICE
■ To prevent 12-volt battery discharge
Do not leave the audio system on longer than necessary when the hybrid
system is stopped.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.
YARIS_HV_OM_Europe_OM52G76E
260
5-1. Basic Operations
Steering wheel audio switches
Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.
Operating the audio system using the
steering wheel switches
1
Volume switch:
• Press: Increases/decreases
volume
• Press and hold: Continuously
increases/decreases volume
2
Radio mode:
• Press: Selects a radio station
• Press and hold: Seeks up/
down
CD, MP3/WMA disc, iPod or USB mode:
• Press: Selects a track/file/song
• Press and hold: Selects a folder or album (MP3/WMA disc, iPod
or USB)
“MODE” switch
3
• Press: Turns the power on, selects an audio source
• Press and hold: Mutes or pauses the current operation.
To cancel the mute or pause, press and hold again.
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
YARIS_HV_OM_Europe_OM52G76E
5-1. Basic Operations
261
USB port
Connect an iPod, USB memory device or portable audio player
to the USB port as indicated below. Press
to select
“iPod” or “USB”.
Connecting using the USB port
■ iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if
it is not turned on.
5
■ USB memory device
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■ Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
WARNING
■ While driving
Do not connect a device or operate the device controls.
: If equipped
YARIS_HV_OM_Europe_OM52G76E
262
5-2. Using the audio system
Optimal use of the audio system
Sound quality
(treble/bass) and volume balance can be
adjusted.
1
Displays the current mode
2
Changes the following setting
• Sound quality and volume
balance (P. 263)
The sound quality and balance
setting can be changed to pro-
duce the best sound.
• Automatic Sound Levelizer
on/off (P. 263)
3
Selecting the mode
Using the audio control function
■ Changing sound quality modes
1
Press
2
Turn
to select “Sound Setting”.
3
Press
4
Turn
as corresponds to the desired mode.
“BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL”
5
Press
: If equipped
YARIS_HV_OM_Europe_OM52G76E
5-2. Using the audio system
263
■ Adjusting sound quality
Turning
adjusts the level.
Sound
Mode
Turn to the
Turn to the
Level
quality mode
displayed
left
right
Bass*
“BASS”
-5 to 5
Low
High
Treble*
“TREBLE”
-5 to 5
Front/rear
volume
“FADER”
R7 to F7
Shifts to rear
Shifts to front
balance
Left/right
volume
“BALANCE”
L7 to R7
Shifts to left
Shifts to right
balance
*: The sound quality level is adjusted individually in each audio mode.
■ Adjusting the Automatic Sound Levelizer (ASL)
5
When ASL is selected, turning
to the right changes the
amount of ASL in the order of LOW, MID and HIGH.
Turning
to the left turns ASL off.
ASL automatically adjusts the volume and tone quality according to
vehicle speed.
YARIS_HV_OM_Europe_OM52G76E
264
5-3. Using the radio
Radio operation
Select “AM” or “FM” to begin listening to the radio.
1
Power
6
Back button
2
Volume
7
AM/FM mode button
3
Station selector
8
Displays station list
4
AF/region code/
9
Seeking the frequency
TA mode setup
5
Adjusting the frequency or
selecting items
: If equipped
YARIS_HV_OM_Europe_OM52G76E
5-3. Using the radio
265
Setting station presets
1
Search for a desired station by turning
or pressing “” or “”
on
2
Press and hold the button (from
[1] to
[6]) the station
is to be set to until you hear a beep.
Using the station list
■ Updating the station list
1
Press
The station list will be displayed.
2
Press
(UPDATE) to update the list.
“Updating” is displayed while the searching is in process, and then avail-
able stations will be listed on the display.
To cancel the updating process, press
5
■ Selecting a station from the station list
1
Press
The station list will be displayed.
2
Turn
to select a station.
3
Press
to tune in the station.
To return to the previous display, press
YARIS_HV_OM_Europe_OM52G76E
266
5-3. Using the radio
RDS (Radio Data System)
This feature allows your radio to receive station.
■ Listening to stations of the same network
1
Press
2
Turn
to “RADIO” and press
3
Turn
as corresponds to the desired mode: “FM AF” or
“Region code”.
4
Press
to select “ON” or “OFF”.
FM AF ON mode:
The station among those of the same net-
work with strong reception is selected.
Region code ON mode: The station among those of the same net-
work with strong reception and broadcast-
ing the same program is selected.
YARIS_HV_OM_Europe_OM52G76E
5-3. Using the radio
267
■ Traffic information
1
Press
2
Turn
to “RADIO” and press
3
Turn
to “FM TA” mode.
4
Press
to select “ON” or “OFF”.
TP mode: The system automatically switches to traffic information
when a broadcast with a traffic information signal is
received.
The station returns to the previous one when the traffic infor-
mation ends.
TA mode: The system automatically switches to traffic information
when a broadcast with a traffic information signal is
received. In FM modes, the system will be mute unless
5
traffic information is being broadcast.
The audio system returns to the previous mode when the traf-
fic information ends.
YARIS_HV_OM_Europe_OM52G76E
268
5-3. Using the radio
■ EON (Enhanced Other Network) system (for traffic announcement func-
tion)
If the RDS station (with EON data) you are listening to is not broadcasting a
traffic information program and the audio system is in the TA
(traffic
announcement) mode, the radio will be switched automatically to a station
broadcasting a traffic information program in the EON AF list when traffic
information begins.
■ When the battery is disconnected
Stations presets are erased.
■ Reception sensitivity
● Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
● The radio antenna is mounted on the rear roof. The antenna can be
removed from the base by turning it.
■ Digital Audio Broadcast (DAB) radio
The optional radio antenna and tuner are necessary for the use of Digital
Audio Broadcast (DAB) radio.
NOTICE
■ To prevent damage, remove the antenna in the following cases
●The antenna will touch the ceiling of a garage.
●A cover will be put on the roof.
YARIS_HV_OM_Europe_OM52G76E
5-4. Playing audio CDs and MP3/WMA discs
269
CD player operation
Insert a disc or press
to beginning to a disc.
5
1
Power
7
Selecting a folder
2
Volume
8
Back button
3
Disc eject
9
Playback
4
Repeat play
10
Displays track/folder list
5
Random playback
11
Selecting a track, fast-forward-
6
Selecting a track/file or dis-
ing or reversing
plays text message
Loading CDs or MP3 and WMA discs
Insert a disc.
Ejecting CDs or MP3 and WMA discs
Press
and remove the disc.
: If equipped
YARIS_HV_OM_Europe_OM52G76E
270
5-4. Playing audio CDs and MP3/WMA discs
Using the CD player
■ Selecting a track
Turn
or press “” to move up or “” to move down using
until the desired track number is displayed.
■ Selecting a track from a track list
1
Press
The track list will be displayed.
2
Turn and press
to select a track.
To return to the previous display, press
or
■ Fast-forwarding and reversing tracks
To fast-forward or reverse, press and hold “” or “” on
■ Repeat play
Press
(RPT).
The current track is played repeatedly until
(RPT) is pressed
again.
■ Random playback
Press
(RDM).
Tracks are played in a random order until
(RDM) is pressed
again.
■ Switching the display
Press
Track title, Artist name and CD title are shown on the display.
To return to the previous display, press
or
YARIS_HV_OM_Europe_OM52G76E
5-4. Playing audio CDs and MP3/WMA discs
271
Playing back MP3 and WMA discs
■ Selecting a folders one at a time
Press “” or “” on
to select the desired folder.
■ Selecting a folder and file from folder list
1
Press
The folder list will be displayed.
2
Turn and press
to select a folder and a file.
To return to the previous display, press
To exit, press
■ Returning to the first folder
Press and hold “” on
until you hear a beep.
■ Selecting files
5
Turn
or press “” or “” on
to select the desired file.
■ Fast-forwarding and reversing files
To fast-forward or reverse, press and hold “” or “” on
■ Repeat play
Pressing
(RPT) changes modes in the following order:
File repeat Folder repeat* Off.
*: Available except when RDM (random playback) is selected
■ Random playback
Pressing
(RDM) changes modes in the following order:
Folder random Disc random Off.
YARIS_HV_OM_Europe_OM52G76E
