3-1. Key information
119
3
YARIS_HV_OM_Europe_OM52G76E
120
3-1. Key information
YARIS_HV_OM_Europe_OM52G76E
3-1. Key information
121
NOTICE
■ To prevent key damage
●Do not drop the keys, subject them to strong shocks or bend them.
●Do not expose the keys to high temperatures for a long periods of time.
●Do not get the keys wet or wash them in an ultrasonic washer etc.
●Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
●Do not disassemble the keys.
●Do not attach a sticker or anything else to the surface of the key.
●Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems, induction cookers, or medical electrical equipment,
such as low-frequency therapy equipment.
3
■ Carrying the electronic key on your person (vehicles with a smart entry
& start system)
Carry the electronic key 10 cm (3.9 in.) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 10 cm (3.9 in.) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
■ In case of a smart entry & start system malfunction or other key-related
problems (vehicles with a smart entry & start system)
Take your vehicle with all the electronic keys provided with your vehicle to
any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional.
■ When an electronic key is lost (vehicles with a smart entry & start sys-
tem)
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional immediately with all remaining electronic
keys that were provided with your vehicle.
YARIS_HV_OM_Europe_OM52G76E
122
3-2. Opening, closing and locking the doors
Side doors
Unlocking and locking the doors from the outside
The vehicle can be locked and unlocked using the entry function,
wireless remote control, key or door lock switches.
◆ Entry function (vehicles with a smart entry & start system
equipped with entry function)
Carry the electronic key to enable this function.
Grip the handle to unlock the
1
doors.
Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
Touch the lock sensor (the
2
indentation on the side of the
door handle) to lock the
doors.
Check that the door is securely
locked.
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
123
◆ Wireless remote control (if equipped)
Vehicles without a smart entry & start system
Locks all the doors
1
Check that the door is securely
locked.
Unlocks all the doors
2
Vehicles with a smart entry & start system
3
1
Locks all the doors
Check that the door is securely
locked.
2
Unlocks all the doors
◆ Keys (vehicles without a smart entry & start system)
Turning the key operates the doors as follows:
■ Driver’s door
1
Locks all the doors
2
Unlocks all the doors
YARIS_HV_OM_Europe_OM52G76E
124
3-2. Opening, closing and locking the doors
■ Front passenger’s door (vehicles with a key cylinder)
1
Locks the door
2
Unlocks the door
■ Operation signals (vehicles with an entry function or wireless remote
control)
The emergency flashers flash to indicate that the doors have been locked/
unlocked. (Locked: once; Unlocked: twice)
■ Security feature
Vehicles without a smart entry & start system
If a door is not opened within approximately 30 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Vehicles with a smart entry & start system
If a door is not opened within approximately 30 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again. (How-
ever, depending on the location of the electronic key, the key may be
detected as being in the vehicle. In this case, vehicle may be unlocked.)
■ When the door cannot be locked by the lock sensor (vehicles with a
smart entry & start system equipped with entry function)
Use your thumb to push lock sensor.
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
125
■ Door lock buzzer (vehicles with a smart entry & start system equipped
with entry function)
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously. Fully close the door to stop the buzzer, and lock
the vehicle once more.
■ If the entry function (vehicles with a smart entry & start system equipped
with entry function) or the wireless remote control (if equipped) does not
operate properly
● Vehicles without a smart entry & start system: Use the key to lock and
unlock the doors. (P. 123)
● Vehicles with a smart entry & start system: Use the mechanical key to lock
and unlock the doors. (P. 448)
● Replace the key battery with a new one if it is depleted. (P. 369)
3
Unlocking and locking the doors from the inside
◆ Door lock switch
1
Unlocks all the doors
2
Locks all the doors
◆ Inside door lock buttons
1
Locks the doors
2
Unlocks the doors
The front doors can be opened
by pulling the inside handle
even if the inside door lock but-
ton is in the lock position.
YARIS_HV_OM_Europe_OM52G76E
126
3-2. Opening, closing and locking the doors
Locking the front door from the outside without a key
1
Move the inside lock button to the lock position.
2
Close the door while pulling the door handle.
Vehicles without a smart entry & start system
The door cannot be locked if the key is in the power switch.
Vehicles with a smart entry & start system
The door cannot be locked if the power switch is in ACCESSORY or
ON mode, or the electronic key is left inside the vehicle. However, the
key may not be detected correctly and the door may be locked.
Rear door child-protector lock
The door cannot be opened from
inside the vehicle when the lock is
set.
1
Unlock
2
Lock
These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
127
■ Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are
unlocked. Depending on the force of the impact or the type of accident, how-
ever, the system may not operate.
■ Using the mechanical key (vehicles with a smart entry & start system)
The doors can also be locked and unlocked with the mechanical key.
(P. 448)
■ Conditions affecting the operation of the wireless remote control or
smart entry & start system
P. 113, 137
■ If the smart entry & start system has been deactivated in a customized
setting (vehicles with a smart entry & start system)
Use the wireless remote control or mechanical key. (P. 123, 448)
3
WARNING
■ To prevent an accident
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.
●Always use a seat belt.
● Ensure that all the doors are properly closed.
●Do not pull the inside handle of the doors while driving.
The doors may be opened and the passengers are thrown out of the vehi-
cle and it may result in serious injury or death.
Be especially careful for the front doors, as the doors may be opened
even if the inside lock buttons are in locked position.
● Set the rear door child-protector locks when children are seated in the rear
seats.
YARIS_HV_OM_Europe_OM52G76E
128
3-2. Opening, closing and locking the doors
Back door
The back door can be locked/unlocked and opened by the fol-
lowing procedures.
Unlocking and locking the back door
◆ Door lock switch
P. 125
◆ Entry function (vehicles with a smart entry & start system
equipped with entry function)
Carry the electronic key to enable this function.
Press the button to unlock
1
the door.
The door cannot be unlocked for
3 seconds after the door is
locked.
2
Press the button to lock the
door.
Check that the door is securely
locked.
◆ Wireless remote control (if equipped)
P. 123
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
129
◆ Keys
From the back door (vehicles with a back door key cylinder):
1
Unlocks all the doors
2
Locks all the doors
From the driver’s door: P. 123
3
Opening the back door from the outside the vehicle (vehicles
with a smart entry & start system)
Raise the back door while pushing
up the back door opener switch.
The back door cannot be closed
immediately after the back door
opener switch is pushed.
When closing the back door
Lower the back door using the
back door handle, and make sure
to push the back door down from
the outside to close it.
YARIS_HV_OM_Europe_OM52G76E
130
3-2. Opening, closing and locking the doors
■ Operation signals (vehicles with an entry function or wireless remote
control)
P. 124
■ Security feature
P. 124
■ Door lock buzzer (vehicles with a smart entry & start system equipped
with entry function)
P. 125
■ Luggage compartment light
The luggage compartment lights turn on when the back door is opened.
■ If the smart entry & start system has been deactivated in a customized
setting (vehicles with a smart entry & start system)
Use the wireless remote control or mechanical key. (P. 123, 448)
■ If the entry function (vehicles with a smart entry & start system equipped
with entry function) or the wireless remote control (if equipped) does not
operate properly
● Vehicles without a smart entry & start system: Use the key to unlock the
back door. (P. 129)
● Vehicles with a smart entry & start system: Use the mechanical key to
unlock the back door. (P. 448)
● Replace the key battery with a new one if it is depleted. (P. 369)
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
131
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■ Before driving
● Make sure that the back door is fully closed. If the back door is not fully
closed, it may open unexpectedly while driving and hit near-by objects or
luggage in the luggage compartment may be thrown out, causing an acci-
dent.
●Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or other injuries.
●Do not allow a child to open or close the back door.
3
Doing so may cause the back door to open unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.
■ Important points while driving
●Keep the back door closed while driving.
If the back door is left open, it may hit near-by objects or luggage in the
luggage compartment may be thrown out, causing an accident.
●Never let anyone sit in the luggage compartment. In the event of sudden
braking or a collision, they are susceptible to death or serious injury.
■ Operating the back door
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.
●Remove any heavy loads, such as snow and ice, from the back door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.
● When opening or closing the back door, thoroughly check to make sure
the surrounding area is safe.
● If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.
●Use caution when opening or closing the back door in windy weather as it
may move abruptly in strong wind.
YARIS_HV_OM_Europe_OM52G76E
132
3-2. Opening, closing and locking the doors
WARNING
●The back door may suddenly shut if it is
not opened fully. It is more difficult to
open or close the back door on an
incline than on a level surface, so
beware of the back door unexpectedly
opening or closing by itself. Make sure
that the back door is fully open and
secure before using the luggage com-
partment.
● When closing the back door, take extra
care to prevent your fingers etc. from
being caught.
● When closing the back door, make sure
to press it lightly on its outer surface. If
the back door handle is used to fully
close the back door, it may result in
hands or arms being caught.
●Do not pull on the back door damper stay to close the back door, and do
not hang on the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to
break, causing an accident.
● If a bicycle carrier or similar heavy object is attached to the back door, it
may suddenly shut again after being opened, causing someone’s hands,
head or neck to be caught and injured. When installing an accessory part
to the back door, using a genuine Toyota part is recommended.
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
133
NOTICE
■ Back door damper stays
The back door is equipped with damper stays that hold the back door in
place.
Observe the following precautions.
Failure to do so may cause damage to the back door damper stay, resulting
in malfunction.
●Do not attach any foreign objects, such
as stickers, plastic sheets, or adhesives
to the damper stay rod.
●Do not touch the damper stay rod with
gloves or other fabric items.
3
●Do not attach any heavy accessory to
the back door. Toyota recommends
genuine Toyota parts.
●Do not place your hand on the damper
stay or apply lateral forces to it.
YARIS_HV_OM_Europe_OM52G76E
134
3-2. Opening, closing and locking the doors
Smart entry & start system
The following operations can be performed simply by carrying
the electronic key on your person, for example in your pocket.
(The driver should always carry the electronic key.)
● Locks and unlocks the side doors (vehicles with an entry function)
(P. 122)
● Locks and unlocks the back door (vehicles with an entry function)
(P. 128)
● Starts and stops the hybrid system (P. 182)
■ Antenna location
1
Antennas outside the cabin
(vehicles
with an entry function)
2
Antennas inside the cabin
3
Antenna outside the luggage compart-
ment (vehicles with an entry function)
: If equipped
YARIS_HV_OM_Europe_OM52G76E
3-2. Opening, closing and locking the doors
135
■ Effective range (areas within which the electronic key is detected)
When locking or unlocking the doors
(vehicles with an entry function)
The system can be operated when
the electronic key is within about
0.7 m (2.3 ft.) either of the outside
front door handles and back door.
(Only the doors detecting the key
can be operated.)
When starting the hybrid system or changing power switch modes
The system can be operated when the electronic key is inside the vehi-
cle.
■ Alarms and warning indicators
3
A combination of exterior and interior alarms as well as warning lights are
used to prevent theft of the vehicle and unforeseeable accidents resulting
from erroneous operation. Take appropriate measures for the warning light
that comes on. (P. 413)
The following table describes circumstances and correction procedures when
only alarms are sounded.
Alarm
Situation/Actions
• An attempt was made to lock the doors using
the smart entry & start system while the elec-
tronic key was still inside the vehicle.
Retrieve the electronic key from the vehicle
Exterior alarm sounds
and lock the doors again.
once for 5 seconds
• An attempt was made to lock the vehicle while
a door was open.
Close all of the doors and lock the doors
again.
An attempt was made to lock either front door by
opening a door and putting the inside lock button
Interior alarm pings
into the lock position, then closing the door by
once and exterior alarm
pulling on the outside door handle with the elec-
sounds once for 5 sec-
tronic key still inside the vehicle.
onds
Retrieve the electronic key from the vehicle
and lock the doors again.
YARIS_HV_OM_Europe_OM52G76E
