1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

Auto anti-glare inside rear view mirror

During nighttime driving, the auto-dimming feature senses distract-
ing glare from vehicle headlights behind you and automatically
dims to eliminate the glare and preserve your vision.

Press the

switch to turn the

auto-dimming feature on/off. The
auto-dimming feature is enabled
when the switch’s green LED
indicator is on. The auto-dim-
ming feature will default to on
with each ignition cycle.

WARNING

■

Caution while driving

Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

Outside rear view mirrors

Mirror angle can be adjusted using the switch.

Select a mirror to adjust.

Left
Right

Adjust the mirror.

Up
Right
Down
Left

STEP

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

Folding the mirrors

Push the mirror back in the direc-
tion of the vehicle’s rear.

■

The mirrors can be adjusted when

Vehicles without a keyless access with push button start system
The engine switch is in the “ACC” or “ON” position.

Vehicles with a keyless access with push button start system
The push-button ignition switch is in “ACC” or “ON” mode.

■

When the mirrors are fogged up (vehicles with outside rear view mirror
defoggers)

The outside rear view mirrors can be cleared using the mirror defoggers.
Turn on the rear window defogger to turn on the outside rear view mirror
defoggers. (

→P. 298)

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

WARNING

■

When driving the vehicle
Observe the following precautions while driving.

Failure to do so may result in loss of control of the vehicle and cause an

accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly

adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating (vehicles with outside rear

view mirror defoggers)
Do not touch the rear view mirror surfaces, as they can become very hot and
burn you.

BRZ_U

1-4. Opening and closing the windows

Power windows

Window lock switch

Press the switch down to lock
the passenger window glasses.

Use this switch to prevent chil-
dren from accidentally opening or
closing a passenger window.

The power windows can be opened and closed using the switches.

Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

Pushing the switch in the oppo-

site direction will stop window
travel partway.

1-4. Opening and closing the windows

Be
fo

riv

BRZ_U

■

The power windows can be operated when

Vehicles without a keyless access with push button start system
The engine switch is in the “ON” position.

Vehicles with a keyless access with push button start system
The push-button ignition switch is in “ON” mode.

■

Operating the power windows after turning the engine off

Vehicles without a keyless access with push button start system
The power windows can be operated for approximately 40 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either door is opened.

Vehicles with a keyless access with push button start system
The power windows can be operated for approximately 40 seconds even
after the push-button ignition switch is turned to “ACC” mode or turned off.
They cannot, however, be operated once either door is opened.

■

Jam protection function

If an object becomes caught between the window and the body, window
travel is stopped and the window is opened slightly.

1-4. Opening and closing the windows

BRZ_U

■

When the power window does not close normally

If the jam protection function is operating abnormally and a window cannot
be closed, close all the doors perform the following operations using the
power window switch on the relevant door.

Vehicles without a keyless access with push button start system:
After stopping the vehicle, the engine switch is turned to the “ON”
position.

Vehicles with a keyless access with push button start system: After
stopping the vehicle, the push-button ignition switch is turned to
“ON” mode.

Hold the power window switch in the one-touch closing position two
consecutive times.

Hold the power window switch in the one-touch closing position
once again and continue holding for 1 second or more after the win-
dow closes completely.

If you push the power window switch to the opening position while the win-
dow is moving, start again from the beginning. If the window continues to
close but then re-open slightly even after performing the above procedure
correctly, have the vehicle inspected by your SUBARU dealer.

STEP

1-4. Opening and closing the windows

Be
fo

riv

BRZ_U

WARNING

■

Closing the windows

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

Do not allow children to operate the power windows.
Closing a power window on someone can cause death or serious injury.
The driver is responsible for instructing children not to operate the power
windows.

●

Vehicle without a keyless access with push button start system: Before
leaving the vehicle, always remove the key from the engine switch for
safety and never allow an unattended child to remain in the vehicle. Fail-
ure to follow this procedure could result in injury to a child operating the
power window.

●

Vehicle with a keyless access with push button start system: Before leav-
ing the vehicle, always remove the key from the push-button ignition
switch for safety and never allow an unattended child to remain in the vehi-
cle. Failure to follow this procedure could result in injury to a child operat-
ing the power window.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the window fully closes.

BRZ_U

1-5. Refueling

Opening the fuel tank cap

Perform the following steps to open the fuel tank cap:

■

Before refueling the vehicle
● Vehicles without a keyless access with push button start sys-

tem: Turn the engine switch off and ensure that all the doors
and windows are closed.

● Vehicles with a keyless access with push button start system:

Turn the push-button ignition switch off and ensure that all the
doors and windows are closed.

● Confirm the type of fuel. (→P. 79)

■

Opening the fuel tank cap

Pull up the opener to open the
fuel filler lid.

Turn the fuel tank cap slowly
to open.

STEP

1-5. Refueling

Be
fo

riv

BRZ_U

Closing the fuel tank cap

After refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.

Hang the fuel tank cap on the
back of the fuel filler lid.

STEP

■

Fuel types

Unleaded gasoline (93 AKI [98 RON] or higher)

If unleaded gasoline with an octane rating of 93 AKI (98 RON) is not avail-
able, unleaded gasoline with an octane rating of 91 AKI (95 RON) may be
used with no detriment to engine durability or driveability.

1-5. Refueling

BRZ_U

WARNING

■

Refueling the vehicle

Observe the following precautions while refueling the vehicle.
Failure to do so may result in death or serious injury.

●

Do not handle fuel indoors.

●

After exiting the vehicle and before opening the fuel door, touch an
unpainted metal surface to discharge any static electricity. It is important to
discharge static electricity before refueling because sparks resulting from
static electricity can cause fuel vapors to ignite while refueling.

●

Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened.
Wait until the sound cannot be heard before fully removing the cap.
In hot weather, pressurized fuel may spray out of the filler neck and cause
injury.

●

Do not allow anyone that has not discharged static electricity from their
body to come close to an open fuel tank.

●

Do not allow anyone to approach the area of the vehicle near the fuel filler
pipe while refueling is in progress.

●

Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.

●

Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.

●

Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible ignition
hazard.

1-5. Refueling

Be
fo

riv

BRZ_U

WARNING

■

When refueling

Observe the following precautions to prevent fuel overflowing from the fuel
tank:

●

Securely insert the fuel nozzle into the fuel filler neck

●

Stop filling the tank after the fuel nozzle automatically clicks off

●

Do not top off the fuel tank

●

Observe other precautions that are posted at the service station.

●

Turn the cap to the right until it clicks to ensure that it is fully tightened. If
the cap is not securely tightened, fuel spillage could occur in the event of
an accident, creating a fire hazard.

■

When replacing the fuel cap

Do not use anything but a genuine fuel tank cap designed for your vehicle.
Doing so may cause a fire or other incident which may result in death or seri-
ous injury.

CAUTION

■

Refueling

●

Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the emission control
system to operate abnormally or damaging fuel system components or the
vehicle's painted surface.

●

Never add any cleaning agents to the fuel tank. The addition of a cleaning
agent may cause damage to the fuel system.

●

Immediately put fuel in the tank whenever the low fuel warning light illumi-
nates. Engine misfires as a result of an empty tank could cause damage to
the engine. Continuing to operate your vehicle at an extremely low fuel
level may result in a reduction of engine performance.

BRZ_U

1-6. Security system

Engine immobilizer system

The vehicle's keys have built-in transponder chips that prevent the
engine from starting if the key has not been previously registered in
the vehicle's on-board computer.

Never leave the keys inside the vehicle when you leave the vehicle.

This system is designed to help prevent vehicle theft but does not
guarantee absolute security against all vehicle thefts.

Vehicles without a keyless
access with push button
start system
The indicator light flashes after
the key has been removed
from the engine switch to indi-
cate that the system is operat-
ing.

The indicator light stops flash-
ing after the registered key
has been inserted into the
engine switch to indicate that
the system has been can-
celed.

1-6. Security system

Be
fo

riv

BRZ_U

■

When the vehicle cannot be started with the registered key (vehicles
without a keyless access with push button start system)

Remove the key and try again.

■

System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

Vehicles with a keyless
access with push button
start system
The indicator light flashes after
the push-button ignition switch
has been turned off to indicate
that the system is operating.

The indicator light stops flash-
ing after the push-button igni-
tion switch has been turned to
“ACC” or “ON” mode to indi-
cate that the system has been
canceled.

1-6. Security system

BRZ_U

■

Certification for engine immobilizer system

For vehicles sold in the U.S.A.
FCC ID: Y8PSSPIMB03

FCC ID: MOZRI-38BFH

This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC WARNING

Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

For vehicles sold in Canada
NOTE:
This device complies with Industry Canada’s licence-exempt RSSs. Opera-
tion is subject to the following two conditions: (1) This device may not cause
interference; and (2) This device must accept any interference, including
interference that may cause undesired operation of the device.

NOTE:
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.

For vehicles sold in Mexico
Este equipo opera a título secundario, consecuentemente, debe aceptar
interferencias perjudiciales incluyendo equipos de la misma clase y puede
no causar interferencias a sistemas operando a título primario.

1-6. Security system

Be
fo

riv

BRZ_U

CAUTION

■

To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

Content .. 3 4 5 6 ..
