Subaru BRZ (2019 year). Manual - part 4

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

■

Getting out of the rear seats

Pull the seatback fold strap.

The seatback will fold forward.

Front passenger seat only: The
seat can be slid forward and
backward.

■

After getting in or out of the rear seats

Return the seatback to the upright position until the seat locks.

Front passenger seat only: The seat will lock in position at the point where
the seatback reaches the upright position.

■

Seat dust cover

Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat.

WARNING

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

WARNING

●

After adjusting the seat, push it slightly to make sure it is securely locked.
If the seat is not securely locked, it may move or the seatbelt may not
operate properly.

●

Take care not to hit passengers with the seat.
When sliding the seat rearward, make sure not to squash the legs of the
rear passengers.

●

When returning the seatback upright, perform seatback angle adjustment
while holding down the seatback.

●

Do not pull on or use the seatbelt guide to adjust or fold the front seat.

■

When driving the vehicle

Never operate the seatback angle adjustment lever or seatback fold strap.
Doing so could cause an accident resulting in death or serious injury.

■

Getting in and out of the rear seats

●

When getting in or out of the rear seats, make sure not to get your hands,
legs, etc. squashed in the movable or connecting parts.

●

When getting in or out of the rear seats, make sure not to trip on the seat
rails.

●

After getting in or out of the rear seats, always make sure the front seat is
locked in position.

■

When operating the front seat from the rear seat

Make sure that no passenger is seated in the front seat.

CAUTION

■

When getting in and out the vehicle

Do not rub your back against the side support pad of backrest. Otherwise
surface of the side support pad is damaged early. You can move the seat
backward to prevent the contact.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

Rear seats

■

Seat dust cover

Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat.

The seatbacks of the rear seats can be folded down.

Pull the both left and right
seatback lock release straps
in the trunk lid to fold down the
seatback.

To return the seatbacks to its
original position, lift it up until it
locks.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

WARNING

■

When folding the rear seatbacks down

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the select
lever to P (automatic transmission) or shift lever to neutral (manual trans-
mission).

●

Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.

●

Do not allow children to enter the trunk.

■

After returning the rear seatback to the upright position

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Check that the seatbelts are not twisted or caught in the seatback.

■

Before using the rear seatbelts

●

Make sure that the seatback is securely
locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked,
the red portion of the seatback lock
indicator will be visible. Make sure that
the red portion is not visible.

●

Always make sure that the seatbelt is
not caught in the seatback or twisted in
one of the hooks that secure the seat-
back. Failure to do so may cause the
seatbelt to not be fastened correctly or
to become ineffective in a collision,
resulting in serious injury.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

Head restraints

■

Removing the head restraints

■

Installing the head restraints

Head restraints are provided for front seats.

Pull the head restraints up.

Down

Push the head restraint down
while pushing the lock release
button.

Lock release button

Pull the head restraint up while pressing
the lock release button.

Align the head restraint with the installa-
tion holes and push it down to the lock
position.

Press and hold the lock release button
when lowering the head restraint.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

■

Adjusting the height of the head restraints

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure
they are locked in position.

●

Do not drive with the head restraints removed.

Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

Seatbelts

Make sure that all occupants are wearing their seatbelts before driv-
ing the vehicle.

■

Correct use of the seatbelts

● Extend the shoulder belt so

that it comes fully over the
shoulder, but does not
come into contact with the
neck or slide off the shoul-
der.

● Position the lap belt as low

as possible over the hips.

● Adjust the position of the

seatback. Sit up straight
and well back in the seat.

● Do not twist the seatbelt.

■

Fastening and releasing the seatbelt

Fasten the seatbelt

Push the plate into the buckle
until a click sound is heard.

Release the seatbelt

Press the release button.

As the seatbelt is retracted
automatically, make sure that it
is not tangled or twisted.

Release button

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

Front seatbelt guide

To enable the seatbelt to be eas-
ily extended, pass the seatbelt
through the guide.

When getting in or out of the rear
seats, release the seatbelt from
the guide.

Seatbelt pretensioners (front seats)

The pretensioner helps the seat-
belt to quickly restrain the occu-
pant by retracting the seatbelt
when the vehicle is subjected to
certain types of severe frontal or
side collision or a vehicle roll-
over.

The pretensioner may not acti-
vate in the event of a minor frontal
or side impact or a rear impact.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.

■

Automatic locking retractor (ALR)

When a passenger's shoulder belt is completely extended and then
retracted even slightly, the belt is locked in that position and cannot be
extended. This feature is used to hold the child restraint system (CRS) firmly.
To free the belt again, fully retract the belt and then pull the belt out once
more. (

→P. 146)

■

Child seatbelt usage

The seatbelts of your vehicle are principally designed for persons of adult
size.

●

Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle's seatbelt.
(

→P. 141)

●

When the child becomes large enough to properly wear the vehicle's
seatbelt, follow the instructions on P. 60 regarding seatbelt usage.

■

Seatbelt pretensioners

●

Seatbelt pretensioners are not designed to activate in a rear impact or
minor frontal or side impact.

●

The following four components operate simultaneously when the vehicle
is involved in a rollover accidents.

• Seatbelt pretensioner for driver
• Seatbelt pretensioner for front passenger
• SRS curtain airbag for driver’s seat side
• SRS curtain airbag for front passenger’s seat side

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

●

The following four components operate simultaneously when the vehicle
is subjected to a severe frontal collision.

• Seatbelt pretensioner for driver
• Seatbelt pretensioner for front passenger
• SRS front airbag for driver
• SRS front airbag for front passenger*

*: This does not operate while the occupant detection system determines to

deactivate the airbag operation. For details, refer to “Front passenger’s
SRS frontal airbag” (

→P. 101)

●

The following two components operate simultaneously when the vehicle
is subjected to a severe collision on the driver’s seat side of the vehicle.

• Seatbelt pretensioner for driver
• Side airbag for driver

●

The following two components operate simultaneously when the vehicle
is subjected to a severe collision on the front passenger’s seat side of the
vehicle.

• Seatbelt pretensioner for front passenger
• Side airbag for front passenger

●

Pretensioners are designed to function on a one-time-only basis. In the
event that a pretensioner is activated, both the driver’s and front passen-
ger’s seatbelt retractor assemblies must be replaced only by SUBARU
dealer. When replacing seatbelt retractor assemblies for the front seating
positions, use only genuine SUBARU parts equipped with a load limiter.

●

If either front seatbelt does not retract or cannot be pulled out due to a
malfunction or activation of the pretensioner, contact your SUBARU
dealer as soon as possible.

●

If the front seatbelt retractor assembly or surrounding area has been
damaged, contact your SUBARU dealer as soon as possible.

●

When you sell your vehicle, we urge you to explain to the buyer that it
has seatbelt pretensioners by alerting the buyer to the contents of this
section.

■

Replacing the belt after the pretensioner has been activated

If the vehicle is involved in multiple collisions, the pretensioner will activate
for the first collision, but will not activate for the second or subsequent colli-
sions.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

WARNING

Observe the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failure to do so may cause death or serious injury.

■

Wearing a seatbelt

●

Ensure that all passengers wear a seatbelt.

●

Always wear a seatbelt properly.

●

Each seatbelt should be used by one person only. Do not use a seatbelt
for more than one person at once, including children.

●

SUBARU recommends that children be seated in the rear seat and always
use a seatbelt and/or an appropriate child restraint system.

●

To achieve a proper seating position, do not recline the seat more than
necessary. The seatbelt is most effective when the occupants are sitting
up straight and well back in the seats.

●

Do not wear the shoulder belt under your arm.

●

Always wear your seatbelt low and snug across your hips.

■

Pregnant women

Obtain medical advice and wear the seat-
belt in the proper way. (

→P. 60)

Women who are pregnant should position
the lap belt as low as possible over the
hips in the same manner as other occu-
pants. Extend the shoulder belt com-
pletely over the shoulder and position the
belt across the chest. Avoid belt contact
over the rounding of the abdominal area.

If the seatbelt is not worn properly, not
only the pregnant woman, but also the
fetus could suffer death or serious injury
as a result of sudden braking or a colli-
sion.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

WARNING

■

People with a medical condition

Obtain medical advice and wear the seatbelt in the proper way.

■

When children are in the vehicle

Do not allow children to play with the seatbelt. If the seatbelt becomes
twisted around a child’s neck, it may lead to choking or other serious injuries
that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used
to cut the belt.

■

Seatbelt pretensioners

If the pretensioner has activated, the SRS airbag system warning light will
come on. In that case, the seatbelt cannot be used again and must be
replaced at your SUBARU dealer.

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

WARNING

■

Seatbelt damage and wear

●

Do not damage the seatbelts by allowing the belt, plate, or buckle to be
jammed in the door.

●

Inspect the seatbelt system periodically. Check for cuts, fraying, and loose
parts. Replace a damaged seatbelt immediately. Damaged seatbelts can-
not protect an occupant from death or serious injury.

●

Ensure that the belt and plate are locked and the belt is not twisted.
If the seatbelt does not function correctly, immediately contact your
SUBARU dealer.

●

Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there's no obvious damage.

●

Do not attempt to install, remove, modify, disassemble or dispose of the
seatbelts. Have any necessary repairs carried out by your SUBARU
dealer. Inappropriate handling of the pretensioner may prevent it from
operating properly, resulting in death or serious injury.

■

When using the seatbelt guide

●

Always make sure that the belt is not twisted, and runs freely through the
guide.

●

Regardless of whether the guide is used or not, always secure the seatbelt
guide button.

●

Do not hang from or pull the guide forcefully.

■

Before using the rear seatbelts

●

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

Steering wheel

The steering wheel can be adjusted to a comfortable position.

Hold the steering wheel and
push the lever down.

Adjust to the ideal position by
moving the steering wheel
horizontally and vertically.

After adjustment, pull the lever
up to secure the steering
wheel.

STEP

1-3. Adjustable components (seats, mirrors, steering wheel)

BRZ_U

WARNING

■

Caution while driving

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and an accident,
resulting in death or serious injury.

■

After adjusting the steering wheel

●

Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury.

●

Do not put any objects (including straps
or cords) over the steering wheel pad,
steering column cover, or dashboard.

• These objects could become entan-

gled in the steering wheel, prevent-
ing the SRS front airbag, etc. from
operating properly.

• If the SRS front airbag deploys,

these objects could become projec-
tiles, causing injury.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

BRZ_U

Anti-glare inside rear view mirror

Adjusting the height of rear view mirror

Adjust the height of the rear view
mirror by moving it up and down.

Anti-glare function

Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be
reduced by operating the lever.

Normal position
Anti-glare position

The rear view mirror’s position can be adjusted to enable sufficient
confirmation of the rear view in accordance with the driver's seating
posture.

Content .. 2 3 4 5 ..
