Subaru BRZ (2019 year). Manual - part 3

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

Remote keyless entry system

The remote keyless entry system can be used to lock and unlock the
vehicle.

Vehicles without a keyless access with push button start sys-
tem

Locks both side doors

Check that the door is securely
locked.

Sounds the alarm
(press and hold)
Unlocks both side doors

Pressing the button unlocks
the driver’s door. Pressing the
button again within 3 seconds
unlocks the other door.

Unlocks the trunk lid
(press and hold)

Vehicles with a keyless access with push button start system

Locks both side doors

Check that the door is securely
locked.

Unlocks both side doors

Pressing the button unlocks
the driver’s door. Pressing the
button again within 3 seconds
unlocks the other door.

Unlocks the trunk lid
(press and hold)
Sounds alarm
(press and hold)

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

■

Operation signals

Doors:

A buzzer sounds and the hazard warning flashers flash to indicate
that the doors have been locked/unlocked. (Locked: once;
Unlocked: twice)

Trunk lid: A buzzer sounds to indicate that the trunk lid has been unlocked.

■

Door lock buzzer (vehicles with a keyless access with push button
start system)

If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously. Fully close the door to stop the buzzer, and lock
the vehicle once more.

■

Panic mode

Vehicles without a keyless access with push button start system

Vehicles with a keyless access with push button start system

When

is pressed for longer than

about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.

To stop the alarm, press any button on
the transmitter.

When

is pressed for longer than

about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.

To stop the alarm, press any button on
the access key.

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

■

Vehicle finder function

Vehicles without a keyless access with push button start system

Vehicles with a keyless access with push button start system

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

A buzzer (sounds once) and the hazard
warning flashers (flash 3 times) are used
to inform the driver of the vehicle’s loca-
tion.
Press

3 times within 5 seconds

while within a circumference of approxi-
mately 30 ft. (10 m) from of the vehicle.
However, if the interval between the 3
presses is short, the system may not be
activated.This setting must be custom-
ized at your SUBARU dealer.

A buzzer (sounds once) and the hazard
warning flashers (flash 3 times) are used
to inform the driver of the vehicle’s loca-
tion.
Press

3 times within 5 seconds

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

■

Conditions affecting operation

Vehicles without a keyless access with push button start system
The remote keyless entry system may not operate normally in the following
situations:

●

When the transmitter battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electri-
cal noise

●

When carrying a portable radio, cellular phone or other wireless commu-
nication devices

●

When the transmitter is in contact with, or is covered by a metallic object

●

When other transmitters (that emit radio waves) are being used nearby

●

If window tint with a metallic content or metallic objects are attached to
the rear window

Vehicles with a keyless access with push button start system
→P. 31

■

If the remote keyless entry system does not operate properly (vehicles
with a keyless access with push button start system)

Locking and unlocking the doors, unlocking the trunk lid: Use the mechanical
key. (

→P. 470)

■

Key battery depletion

Vehicles without a keyless access with push button start system
If the remote keyless entry system does not operate, the battery may be
depleted. Replace the battery when necessary. (

→P. 387)

Vehicles with a keyless access with push button start system
→P. 35

■

When the access key battery is fully depleted
→P. 387

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your SUBARU dealer for details.

■

Customization that can be configured at your SUBARU dealer

Settings (e.g. remote keyless entry system) can be changed.
(Customizable features

→P. 515)

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

■

Certification for remote keyless entry system

For vehicles sold in the U.S.A.
FCC ID: HYQ23AAA

FCC ID: HYQ12BBY

NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC WARNING:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.

For vehicles sold in Canada
NOTE:
This device complies with Industry Canada’s licence-exempt RSSs. Opera-
tion is subject to the following two conditions: (1) This device may not cause
interference; and (2) This device must accept any interference, including
interference that may cause undesired operation of the device.

NOTE:
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

Doors

The vehicle can be locked and unlocked using the “keyless access”
entry function, remote keyless entry system, key or power door lock
switch.

■

“Keyless access” entry function (vehicles with a keyless
access with push button start system)
→P. 26

■

Remote keyless entry system
→P. 38

■

Key

Turning the key operates the doors as follows:

Vehicles without a keyless access with push button start sys-
tem

Locks driver’s side door
Unlocks driver’s side door

Vehicles with a keyless access with push button start system
The doors can also be locked and unlocked with the mechanical
key. (

→P. 470)

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

Locking the doors from the outside without a key

Move the lock lever to the lock position.
Close the door.

Vehicles with a keyless access with push button start system

The door cannot be locked if the access key is left inside the vehi-
cle.

The key may not be detected correctly and the door may be locked.

■

Power door lock switch

Locks both side doors
Unlocks both side doors

■

Lock lever

Locks the door
Unlocks the door

STEP

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

■

Window open/close function linked to door operation

In order to make opening and closing the doors easier, completely closed
windows are linked to door operations. Therefore, when a door is opened, its
window opens slightly. When a door is closed, its window closes completely.

However, if the battery has discharged or is disconnected, this function will
not operate. (

→P. 478)

■

If the keyless access with push button start system has been deacti-
vated in a customized setting (vehicles with a keyless access with
push button start system)

Use the remote keyless entry system or mechanical key. (

→P. 38, 470)

WARNING

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.

●

Always use a seatbelt.

●

Always lock both side doors.

●

Ensure that both side doors are properly closed.

●

Do not pull the inside handle of the doors while driving.
The doors may be opened and the passengers are thrown out of the vehi-
cle and it may result in serious injury or death.

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

Trunk lid

The trunk lid can be opened using the key, trunk lid opener, “keyless
access” entry function or remote keyless entry system.

■

Opening the trunk lid from inside the vehicle

Press and hold the opener
switch to release the trunk lid.

If the trunk lid cannot be
opened by the opener switch:

→

P. 47

■

Opening the trunk lid from outside the vehicle

Key (vehicles without a keyless access with push button start
system)

Turn the master key clockwise
to release the trunk lid.

“Keyless access” entry function (vehicles with a keyless
access with push button start system)

→

P. 26

Remote keyless entry system

→

P. 38

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

Canceling the trunk lid opener feature

To protect luggage stored in the trunk lid against theft, do the follow-
ing:

Turn the main switch in the trunk
lid off to disable the trunk lid
opener.

On (The trunk lid can be
opened using the trunk lid
opener.)
Off (The trunk lid cannot be
opened using the trunk lid
opener.)

Vehicles without a keyless access
with push button start system:
The trunk lid can only be opened
with the master key.

Vehicles with a keyless access
with push button start system:
The trunk lid can only be opened
with the mechanical key.

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

■

Trunk light

The trunk light turns on when the trunk lid is opened.

■

Function to prevent the trunk lid being locked with the access key
inside (vehicles with a keyless access with push button start system)

●

When all doors are being locked, closing the trunk lid with the access key
left inside the trunk will sound an alarm.
In this case, the trunk lid can be opened using the “keyless access” entry
function.

●

Even when the spare access key is put in the trunk with all the doors
locked, the key confinement prevention function can be activated so the
trunk lid can be opened. In order to prevent theft, take all access keys
with you when leaving the vehicle.

●

Even when the access key is put in the trunk with all the doors are
locked, the key may not be detected depending on the places and the
surrounding radio wave conditions. In this case, the key confinement pre-
vention function cannot be activated, causing the doors to lock when the
trunk lid is closed. Make sure to check where the key is before closing
the trunk lid.

●

The key confinement prevention function cannot be activated if any one
of the doors is unlocked. In this case, open the trunk lid using the trunk lid
opener.

■

Internal trunk lid release lever

■

Using the mechanical key (vehicles with a keyless access with push
button start system)

The trunk lid can be also opened using the mechanical key. (

→P. 470)

The trunk lid can be opened by pulling on
the glow-in-the-dark lever located on the
inside of the trunk lid.

The lever will continue to glow for some
time after the trunk lid is closed.

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

■

Which key to the vehicle is to leave with a parking attendant after dis-
abling the trunk lid opener main switch
→P. 23

WARNING

■

Caution while driving

●

Keep the trunk lid closed while driving.
If the trunk lid is left open, it may hit nearby objects while driving or lug-
gage in the trunk may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the trunk lid before driving.

●

Before driving the vehicle, make sure that the trunk lid is fully closed. If the
trunk lid is not fully closed, it may open unexpectedly while driving, caus-
ing an accident.

●

Never let anyone sit in the trunk. In the event of sudden braking or a colli-
sion, they are susceptible to death or serious injury.

■

When children are in the vehicle

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Do not allow children to enter the trunk.
If a child is accidentally locked in the trunk, they could overheat or suffo-
cate.

●

Do not allow a child to open or close the trunk lid.
Doing so may cause the trunk lid to operate unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing trunk lid.

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

WARNING

■

Using the trunk

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.

●

Remove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to fall closed again
after it is opened.

●

When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the trunk lid is about to open or close.

●

Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.

●

The trunk lid may fall if it is not
opened fully. It is more difficult to
open or close the trunk lid on an
incline than on a level surface, so
beware of the trunk lid unexpectedly
opening or closing by itself. Make
sure that the trunk lid is fully open
and secure before using the trunk.

1-2. Opening, closing and locking the doors and trunk lid

Be
fo

riv

BRZ_U

WARNING

●

Do not attach any accessories other than genuine parts to the trunk lid.
Such additional weight on the trunk lid may cause the lid to fall closed
again after it is opened.

■

Trunk lid damper stays

Do not pull on or disassemble the trunk lid damper stays, or dispose of them
in a fire. Illustrations on the trunk lid damper stays indicate the following:

●

When closing the trunk lid, observe
the following precautions:

• Take extra care to prevent your

fingers etc. from being caught.

• Do not place your hand(s)

between the rear spoiler and trunk
lid when closing the trunk lid.

• To close the trunk lid, press the

rear spoiler on either of the por-
tions .

: Do not pull

: Do not disassemble

: Do not dispose of in fire

1-2. Opening, closing and locking the doors and trunk lid

BRZ_U

CAUTION

■

Trunk lid damper stays

The trunk lid is equipped with damper stays that hold the trunk lid in place.
Observe the following precautions.
Failure to do so may cause damage to trunk lid damper stays, resulting in a
malfunction.

●

Do not attach any foreign objects such as stickers, plastic sheets and
adhesives to damper stay rods.

●

Do not touch damper stay rods with gloves or other fabric items.

●

Do not attach any accessories other than genuine parts to the trunk lid.

●

Do not apply lateral force to damper stays or place your hand on it.

Be
fo

riv

BRZ_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Front seats

Getting in and out of the rear seats

To get in and out of the rear seats, use the seatback angle adjust-
ment lever or seatback fold strap.

■

Before getting in or out of the rear seats

Release the seatbelt from the seatbelt guide. (

→P. 61)

■

Getting in the rear seats

Lift the seatback angle adjust-
ment lever.

The seatback will fold forward.

Front passenger seat only: The
seat can be slid forward and
backward.

Seat position adjustment
lever
Seatback angle adjustment
lever
Vertical height adjustment
lever (driver’s side only)
Seatback fold strap

Content .. 1 2 3 4 ..
